11 Description

Display Corlo Touch KNX 5in • Status: 30.08.2021 • Technical changes and errors reserved.

CAUTION!

Live voltage!

There are unprotected live components inside the device.

• Inspect the device for damage before installation. Only put undamaged

devices into operation.

• Comply with the locally applicable directives, regulations and provisions for

electrical installation.

• Immediately take the device or system out of service and secure it against

unintentional switch-on if risk-free operation is no longer guaranteed.

Use the device exclusively for building automation and observe the operating instruc-

tions. Improper use, modifications to the device or failure to observe the operating ins-

tructions will invalidate any warranty or guarantee claims.

Operate the device only as a fixed-site installation, i.e. only in assembled condition and

after conclusion of all installation and operational start-up tasks, and only in the sur-

roundings designated for it.

Elsner Elektronik is not liable for any changes in norms and standards which may occur

after publication of these operating instructions.

1.2.1. Installation

Assembly site and assembly preparations

The device must only be installed and operated in dry, indoor

spaces. Avoid condensation.

ATTENTION!

The WLAN range for the Corlo Touch KNX 5in WL model can be

reduced as a result of the position where it is installed.

Consider this when planning the location.

Avoid direct light (sunlight, lights) when choosing the assembly site. The proximity

sensor's function can be impaired by strong light sources.

Choose the assembly height based on the application in each case: When used as a

switch, the Corlo Touch KNX 5in should be mounted 110 cm above ground level and

when used as an indicating and control display, at a conveniently legible height, say

150 cm.

The Display Corlo Touch KNX 5in is installed in a junction box (R 60 mm, depth 42

mm).
