10 Description

Display Corlo Touch KNX 5in • Status: 30.08.2021 • Technical changes and errors reserved.

The product conforms with the provisions of EU guidelines.

1.1.3. Customizing options

Colours for display edge and housing

The standard colour for the display edge and housing is glossy black. Special paints

are possible, e. g. to RAL or automobile paint colour codes. Please ask for your desired

colour.

The glass pane is only available with black painting, special colours are not possible.

1.2. Installation and start-up

Installation, testing, operational start-up and troubleshooting should

only be performed by an authorised electrician.

Power consumption

Corlo Touch KNX 5in WL

• approx. 3.5 W maximum (when ambient lighting

100% white, display brightness 100%)

• approx. 2.4 W in normal operation (when ambient

lighting off, display brightness 50%)

• approx. 1.9 W in standby operation (when ambient

lighting off, display off)

• During startup briefly approx. 4.8 W (200 mA)

(was measured with 24 V auxiliary voltage)

Data output/

bus communication

KNX +/- Bus connector terminal

Group addresses max. 1024

Assignments max. 1024

Communication objects 1022

Other data interfaces Micro SD

Browser QT Webkit

Inputs 4× Analog/digital,

max. cable length 10 m

Setting range of temperature

sensor T-NTC at input of

Corlo Touch

-40°C...+80°C

Supported WLAN Standards

Corlo Touch KNX 5in WL

IEEE802.11b/g/n, 2.4 GHz or 5 GHz

Supported WLAN Security

Corlo Touch KNX 5in WL

64/128-bit WEP, WPA-PSK, WPA2-PSK
