9 Description

Display Corlo Touch KNX 5in • Status: 30.08.2021 • Technical changes and errors reserved.

1.1.1. Deliverables

• Display unit with mounting unit and fixing screw

• Connection line

Optional accessories:

(not included in the deliverables):

• T-NTC temperature sensor (No. 30516)

• Micro SD card for image data (off the shelf)

1.1.2. Technical data

Housing Glass: real glass, tempered

Housing: plastic

Display Visible diagonal: 5 inches

Resolution: 800 × 480 pixel

Viewing Angle: 12 o’clock viewing direction

Opening angle x: -70° to +70° typ.

Opening angle y: -60° to +60° typ.

Colours • Black glass, edge glossy black

• Custom colours on request (see

Colours for display edge and housing, Seite 10)

Assembly on device socket according to DIN 49073

Degree of protection IP20

Dimensions Housing overall approx. 133 × 97 × 35

(W × H × D, mm), Mounting depth approx. 20 mm

Weight display unit

Corlo Touch KNX 5in

approx. 200 g

Weight display unit

Corlo Touch KNX 5in WL

approx. 210 g

Ambient temperature Operation 0...+50°C, storage -10...+50°C

Ambient humidity 5...95% RH, avoid condensation

Operating voltage 21,6…26,4 V DC.

A suitable power pack can be purchased from

Elsner Elektronik.

Bus current approx. 10 mA

Power consumption

Corlo Touch KNX 5in

• approx. 2.7 W maximum (when ambient lighting

100% white, display brightness 100%)

• approx. 2.0 W in normal operation (when ambient

lighting off, display brightness 50%)

• approx. 1.4 W in standby operation (when ambient

lighting off, display off)

(was measured with 24 V auxiliary voltage)
