6 Description
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
Integrated PI-controllers control ventilation (according to humidity or CO
2
-concentra-
tion) and/or heating/cooling (according to temperature), depending on the respective
model.
Cala Touch KNX features a touch display that shows various display and control pag-
es depending on the individual configuration. There is one page available that shows
the current measured values, a menu area to adjust device settings and pages with
touch control elements for internal temperature control, for light (manual switching or
dimming), for shades or windows (manual operation).
Cala Touch KNX is supplemented with a frame of the switch series used in buildings,
and thus fits seamlessly into the interior fittings.
Common features in all models:
• Colour touch display with display and operating pages for
- 1× display of current measured values
- 1× display of bus data (4 universal spaces)
- 1× temperature control (incl. mode change, indication whether heating/
cooling active); can also be used as an extension unit for operating another
controller
- 3× drive operation (shading, window) with buttons, slider, position display
(incl. slat position)
- 3× switching or dimming of light (with percentage display)
- 1× RGB light control
- 1× light colour temperature setting
- 1× HCL control (adaption of light color temperature over adjustable periods of
time)
- 1× scenes (4 scenes with recall, storage, status indication)
- weekly timer switch with 8 periods
- 2× info page (each displays 2 text objects)
- device settings
• Screen saver (clock, clock/indoor/outdoor temperature alternately, off) may
be switched on or off
• Key tone may be switched on or off
• 4 inputs for binary contacts or T-NTC temperature sensor.
• 8 AND and 8 OR logic gates each with 4 inputs. All switching events as well
as 16 logic inputs (in the form of communications objects) can be used as
inputs for the logic gates. The output from each gate can be configured
optionally as 1-bit or 2 x 8-bit
• 8 multi-function modules (computers) for changing the input data by
calculations, by querying a condition or by converting the data point type
• 4 manipulated variable comparators to output minimum, maximum or
average values. 5 inputs each for values received via communication objects
• Summer compensation for cooling systems. A characteristic curve matches
the target temperature in the room to the external temperature and sets the
minimum and maximum target temperature values
