5 Installation and commissioning

Cala KNX T 201/202 Sunblind push button • Version: 04.10.2021 • Technical changes and errors excepted.

• Base plate

Additionally required (not included in the deliverables):

• Device socket according to DIN 49073

• Frame (for insert 55 x 55 mm), compatible to the switch scheme used in the

building

1.2. Technical specifications

The product conforms with the provisions of EU guidelines.

1.2.1. Accuracy of the measurement

Measurement variations from permanent sources of interference (see chapter

Installation position) can be corrected in the ETS in order to ensure the specified

accuracy of the sensor (offset).

When measuring temperature, the self-heating of the device is compensated.

2. Installation and commissioning

Installation, testing, operational start-up and troubleshooting should

only be performed by an authorised electrician.

Casing Genuine glass, plastic

Colours • similar to RAL 9010 pure white

• similar to RAL 9005 deep black

Installation on device socket according to DIN 49073

Degree of protection IP 20

Dimensions Housing approx. 55 x 55 (W x H, mm),

Installation depth approx. 10 mm,

Base plate approx. 71 x 71 (W x H, mm),

Total weight approx. 50 g

Ambient temperature Operating 0…+55°C, storage -30…+85°C

Ambient humidity 5…95% RH, avoid condensation

Operating voltage KNX bus voltage

Bus current max. 20 mA

Data output KNX +/- Bus plug-in terminal

Group addresses max. 167

Allocations max. 167

Communication objects Cala KNX T 201 Sunblind: 92

Cala KNX T 202 Sunblind: 98

Temperature measurement

range

0…+55°C

Temperature resolution 0.1°C
