20 Setting the parameters

Cala KNX T 201/202 Sunblind Push Button • Version: 04.10.2021 • Technical changes and errors excepted

Specify when the current control variables are to be sent to the bus. Periodic trans-

mission is safer if a message does not reach a recipient. You may also set up periodical

monitoring by the actuator with this setting.

The status object reports the current status of the output (0 = OFF, 0 = ON) and may

for example be used for visualisation, or to switch off the heating pump as soon as the

heating is switched off.

Then define the type of setting. Heating and/or cooling may be controlled in two

stages.

General setpoint values

You may enter separate setpoint values for each mode or use the comfort setpoint as

a basic value.

If you are using the controls for both heating and cooling, you may also select the set-

ting "separately with switching object". Systems used for cooling in the summer and

for heating in the winter can thus be switched from one to the other.

If you are using the basic value, only the deviation from the comfort setpoint value is

listed for the other modes (e. g., 2°C less for standby mode).

Send control variable • on change

• on change and periodically

from change of (in % absolute) 1...10; 2

Cycle

(if sent periodically)

5 s • ... • 5 min • … • 2 h

Send status objects • on change

• on change to 1

• on change to 0

• on change and periodically

• on change to 1 and periodically

• on change to 0 and periodically

Cycle

(if sent periodically)

5 s • ... • 5 min • … • 2 h

Type of control • Single stage heating

• Dual-stage heating

• Single-stage cooling

• Single-stage heating + single-stage cool-

ing

• Dual-stage heating + single-stage cooling

• Dual-stage heating + dual-stage cooling

Keep modified setpoints after mode

change

No • Yes

Setting the nominal values • separate with switching object

• separate without switching object

• with comfort setpoint as a basis with

switching object

• with comfort setpoint as a basis without

switching object
