19 Setting the parameters

Cala KNX T 201/202 Sunblind Push Button • Version: 04.10.2021 • Technical changes and errors excepted

General rules

Decide in which cases nominal values and delay times received per object are to be

kept. The parameter is only taken into consideration if the setting by object is activated

further down. Please note that the setting "After power restoration and programming"

should not be used for the initial start-up, as the factory settings are always used until

the first call (setting via objects is ignored).

For an adequate regulation of the indoor temperature, comfort, standby, eco and build-

ing protection modes may be used.

Comfort when present,

Standby when absent,

Eco as a night-time mode and

Frost / heat protection (building protection) e.g. when the window is open.

The settings for the temperature control include the setpoint temperatures for the in-

dividual modes. Objects are used to determine which mode is to be selected. A change

of mode may be triggered manually or automatically (e.g. by a timer, window contact).

The mode may be switched with two 8 bit objects of different priority. Objects

„... HVAC mode (Prio 2)“ for switching in everyday operation and

„... HVAC mode (Prio 1)“ for central switching with higher priority.

The objects are coded as follows:

0 = Auto

1 = Comfort

2 = Standby

3 = Eco

4 = Building protection

Alternatively, you can use three objects, with one object switching between eco and

standby mode and the two others are used to activate comfort mode or frost/heat pro-

tection mode. The comfort object then blocks the eco/standby object, and frost/heat

protection objects have the highest priority. Objects

„... Mode (1: Eco, 0: Standby)“,

„... comfort activation mode" and

„... frost/heat protection activation mode"

Select the mode to be activated after reset (e.g. power failure, reset of the line via

the bus). (Default).

Then configure a temperature control block using the blocking object.

Switch mode via • two 8-bit objects (HVAC modes)

• three 1-bit objects

Mode after reset • Comfort

• Standby

• Eco

• Building protection

Behaviour of the blocking object with value • 1 = Block | 0 = release

• 0 = block | 1 = release

Value of the blocking object after reset 0 • 1
