15 Setting the parameters

Cala KNX T 201/202 Sunblind Push Button • Version: 04.10.2021 • Technical changes and errors excepted

9. Setting the parameters

9.1. Behaviour on power failure/ restoration of

power

Behaviour following a failure of the bus power supply:

The device sends nothing.

Behaviour on bus restoration of power and following programming or reset:

The device sends all outputs according to their send behaviour set in the parameters

with the delays established in the "General settings" parameter block.

9.2. General settings

Set the basic properties of the data transmission.

9.3. Temperature measured value

Select, whether a malfunction object is to be sent if the sensor is faulty.

Use Offsets to adjust the readings to be sent.

The unit can calculate a mixed value from its own reading and an external value. Set

the mixed value calculation if desired. If an external portion is used, all of the following

settings (threshold values, etc.) are related to the overall reading.

130 OR logic 2: 8 bit output A Output R-CT depending on setting 1 Byte

131 OR logic 2: 8 bit output B Output R-CT depending on setting 1 Byte

132 OR logic 2: Block Input -WC- [1.1] DPT_Switch 1 Bit

Transmission delay after reset/bus restora-

tion

5 s • ... • 300 s

Maximum message rate • 1 message per second

• ...

• 10 messages per second

• ...

• 50 messages per second

Use malfunction object No • Yes

Offset in 0.1°C -50…50; 0

Use external measured value No • Yes

Ext. Reading proportion of the total reading 5% • 10% • ... • 50% • ... • 100%
