16 Setting the parameters

Cala KNX T 201/202 Sunblind Push Button • Version: 04.10.2021 • Technical changes and errors excepted

The minimum and maximum readings can be saved and sent to the bus. Use the

"Reset temperature min/max. value" objects to reset the values to the current readings.

The values are not retained after a reset.

9.4. Temperature threshold values

Activate the required temperature threshold values. The menus for the further setting

of the threshold values are then displayed.

9.4.1. Threshold value 1, 2

Threshold value

Decide in which cases threshold values and delay times received are to be kept per

object. The parameter is only taken into consideration if the setting by object is activat-

ed further down. Please note that the setting "After power restoration and program-

ming" should not be used for the initial start-up, as the factory settings are always used

until the first call (setting via objects is ignored).

Set the threshold values directly in the application program using parameters, or de-

fine them via the bus using a communication object.

Threshold value setpoint using parameter:

Set the threshold values and hysteresis directly.

Sending pattern for internal and total

measured value

• never

• periodically

• on change

• on change and periodically

At and above change of

(if sent on change)

0.1°C • 0.2°C • 0.5°C • ... • 5.0°C

Send cycle

(if sent periodically)

5 s • 10 s • ... • 2 h

Use minimum and maximum value No • Yes

Use threshold value 1 / 2 Yes • No

Maintain the

threshold values and delays received via

communication objects

• never

• after power supply restoration

• after power supply restoration and pro-

gramming

Threshold value setpoint using Parameter • Communication objects

Threshold in 0.1°C -300… 800; 200
