14 Transmission protocol

Cala KNX T 201/202 Sunblind Push Button • Version: 04.10.2021 • Technical changes and errors excepted

Only for Cala KNX T 202 Sunblind

94 LED 3 on/off Input -WC- [1.1] DPT_Switch 1 Bit

95 LED 3 Block Input -WC- [1.1] DPT_Switch 1 Bit

96 LED 4 on/off Input -WC- [1.1] DPT_Switch 1 Bit

97 LED 4 Block Input -WC- [1.1] DPT_Switch 1 Bit

For all models

99 Area operation on/off Input -WC- [1.1] DPT_Switch 1 Bit

100 Area operation Output: Switch Output R-CT depending on setting 2 Bytes

101 Drive 1 Long-term Output R-CT [1.8] DPT_UpDown 1 Bit

102 Drive 1 Short-term Output R-CT [1.10] DPT_Start 1 Bit

Only for Cala KNX T 202 Sunblind

103 Drive 2 Long-term Output R-CT [1.8] DPT_UpDown 1 Bit

104 Drive 2 Short-term Output R-CT [1.10] DPT_Start 1 Bit

For all models

107 Logic input 1 Input -WC- [1.2] DPT_Bool 1 Bit

108 Logic input 2 Input -WC- [1.2] DPT_Bool 1 Bit

109 Logic input 3 Input -WC- [1.2] DPT_Bool 1 Bit

110 Logic input 4 Input -WC- [1.2] DPT_Bool 1 Bit

111 Logic input 5 Input -WC- [1.2] DPT_Bool 1 Bit

112 Logic input 6 Input -WC- [1.2] DPT_Bool 1 Bit

113 Logic input 7 Input -WC- [1.2] DPT_Bool 1 Bit

114 Logic input 8 Input -WC- [1.2] DPT_Bool 1 Bit

117 AND logic 1: 1 bit switching

output

Output R-CT [1.2] DPT_Bool 1 Bit

118 AND logic 1: 8 bit output A Output R-CT depending on setting 1 Byte

119 AND logic 1: 8 bit output B Output R-CT depending on setting 1 Byte

120 AND logic 1: Block Input -WC- [1.1] DPT_Switch 1 Bit

121 AND logic 2: 1 bit switching

output

Output R-CT [1.2] DPT_Bool 1 Bit

122 AND logic 2: 8 bit output A Output R-CT depending on setting 1 Byte

123 AND logic 2: 8 bit output B Output R-CT depending on setting 1 Byte

124 AND logic 2: Block Input -WC- [1.1] DPT_Switch 1 Bit

125 OR logic 1: 1 bit switching out-

put

Output R-CT [1.2] DPT_Bool 1 Bit

126 OR logic 1: 8 bit output A Output R-CT depending on setting 1 Byte

127 OR logic 1: 8 bit output B Output R-CT depending on setting 1 Byte

128 OR logic 1: Block Input -WC- [1.1] DPT_Switch 1 Bit

129 OR logic 2: 1 bit switching out-

put

Output R-CT [1.2] DPT_Bool 1 Bit

No Text Function Flags DPT type Size
