13 Transmission protocol
Cala KNX T 201/202 Sunblind Push Button • Version: 04.10.2021 • Technical changes and errors excepted
68 Temp.control: Setpoint Eco
cooling (1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 Bit
69 Temp.control: Control variable
heating (level 1)
Output R-CT [5.1] DPT_Scaling 1 Byte
70 Temp.control: Control variable
heating (level 2)
Output R-CT [5.1] DPT_Scaling 1 Byte
71 Temp.control: Control variable
cooling (level 1)
Output R-CT [5.1] DPT_Scaling 1 Byte
72 Temp.control: Control variable
cooling (level 2)
Output R-CT [5.1] DPT_Scaling 1 Byte
73 Temperature control: Variable
for 4/6-way valve
Output R-CT [5.1] DPT_Scaling 1 Byte
74 Temp.control: Status Heat.
level 1 (1=ON|0=OFF)
Output R-CT [1.1] DPT_Switch 1 Bit
75 Temp.control: Status Heat.
level 2 (1=ON|0=OFF)
Output R-CT [1.1] DPT_Switch 1 Bit
76 Temp.control: Status Cool.
level 1 (1=ON|0=OFF)
Output R-CT [1.1] DPT_Switch 1 Bit
77 Temp.control: Status Cool.
level 2 (1=ON|0=OFF)
Output R-CT [1.1] DPT_Switch 1 Bit
78 Temp.control: Comfort exten-
sion status
Input /
Output
RWCT [1.1] DPT_Switch 1 Bit
79 Temp.control: Comfort Exten-
sion time
Input RWCT [7.5] DPT_TimePeriod-
Sec
2 Bytes
80 Temp. Controller: Fan coil lev-
els 0 to 3
Output R-CT [5.1] DPT_Scaling 1 Byte
81 Temp. Controller: Fan coil level
1
Output R-CT [1.1] DPT_Switch 1 Bit
82 Temp. Controller: Fan coil level
2
Output R-CT [1.1] DPT_Switch 1 Bit
83 Temp. Controller: Fan coil level
3
Output R-CT [1.1] DPT_Switch 1 Bit
84 Temp. Controller: Fan coil
auto=1 manual=0
Input /
Output
RWCT [1.1] DPT_Switch 1 Bit
86 All LEDs On/Off Input -WC- [1.1] DPT_Switch 1 Bit
87 All LEDs Brightness Input -WC- [5.1] DPT_Scaling 1 Byte
88 LEDs Temperature display On/
Off
Input -WC- [1.1] DPT_Switch 1 Bit
89 LEDs Temperature display
Block
Input -WC- [1.1] DPT_Switch 1 Bit
90 LED 1 on/off Input -WC- [1.1] DPT_Switch 1 Bit
91 LED 1 Block Input -WC- [1.1] DPT_Switch 1 Bit
92 LED 2 on/off Input -WC- [1.1] DPT_Switch 1 Bit
93 LED 2 Block Input -WC- [1.1] DPT_Switch 1 Bit
No Text Function Flags DPT type Size
