12 Transmission protocol

Cala KNX T 201/202 Sunblind Push Button • Version: 04.10.2021 • Technical changes and errors excepted

37 Temp. thresholdV 2: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 Bit

38 Temp. thresholdV 2: Switching

delay from 0 to 1

Input -WC- [7.5] DPT_TimePeriod-

Sec

2 Bytes

39 Temp. thresholdV 2: Switching

delay from 1 to 0

Input -WC- [7.5] DPT_TimePeriod-

Sec

2 Bytes

40 Temp. thresholdV 2: Switching

output

Output R-CT [1.1] DPT_Switch 1 Bit

41 Temp. thresholdV 2: Switching

output block

Input -WC- [1.1] DPT_Switch 1 Bit

50 Temp.control: HVAC mode (pri-

ority 1)

Input /

Output

RWCT depending on setting 1 Byte

51 Temp.control: HVAC mode (pri-

ority 2)

Input /

Output

RWCT depending on setting 1 Byte

52 Temp.control: Mode frost/heat

protection activt.

Input RWCT [1.1] DPT_Switch 1 Bit

53 Temp.control: Block (1 = Block-

ing)

Input -WC- [1.1] DPT_Switch 1 Bit

54 Temp.control: Current setpoint Output R-CT [9.1] DPT_Value_Temp 2 Bytes

55 Temp.control: Switch. (0: Heat-

ing | 1: Cooling)

Input -WC- [1.1] DPT_Switch 1 Bit

56 Temp.control: Setpoint Com-

fort heating

Input /

Output

RWCT [9.1] DPT_Value_Temp 2 Bytes

57 Temp.control: Setpoint Com-

fort heat.(1:+ | 0:-)

Input -WC- [1.1] DPT_Switch 1 Bit

58 Temp.control: Setpoint Com-

fort cooling

Input /

Output

RWCT [9.1] DPT_Value_Temp 2 Bytes

59 Temp.control: Setpoint Com-

fort cool.(1:+ | 0:-)

Input -WC- [1.1] DPT_Switch 1 Bit

60 Temp.control: Basic 16-bit set-

point shift

Input -WC- [9.1] DPT_Value_Temp 2 Bytes

61 Temp.control: Setpoint

Standby heating

Input /

Output

RWCT [9.1] DPT_Value_Temp 2 Bytes

62 Temp.control: Setpoint

Standby heat.(1:+ | 0:-)

Input -WC- [1.1] DPT_Switch 1 Bit

63 Temp.control: Setpoint

Standby cooling

Input /

Output

RWCT [9.1] DPT_Value_Temp 2 Bytes

64 Temp.control: Setpoint

Standby cool. (1:+ | 0:-)

Input -WC- [1.1] DPT_Switch 1 Bit

65 Temp.control: Setpoint Eco

heating

Input /

Output

RWCT [9.1] DPT_Value_Temp 2 Bytes

66 Temp.control: Setpoint Eco

heating (1:+ | 0:-)

Input -WC- [1.1] DPT_Switch 1 Bit

67 Temp.control: Setpoint Eco

cooling

Input /

Output

RWCT [9.1] DPT_Value_Temp 2 Bytes

No Text Function Flags DPT type Size
