11 Transmission protocol

Cala KNX T 201/202 Sunblind Push Button • Version: 04.10.2021 • Technical changes and errors excepted

8. Transmission protocol

Units:

Temperatures in degrees Celsius

8.1. List of all communication objects

Abbreviations Flags:

C Communication

R Read

WWrite

T Transmit

UUpdate

No Text Function Flags DPT type Size

0 Software version Output R-CT [217.1] DPT_Version 2 Bytes

20 Temperature sensor: malfunc-

tion

Output R-CT [1.1] DPT_Switch 1 Bit

21 Temperature sensor: meas-

ured value external

Input -WCT [9.1] DPT_Value_Temp 2 Bytes

22 Temperature sensor: meas-

ured value

Output R-CT [9.1] DPT_Value_Temp 2 Bytes

23 Temperature sensor: meas-

ured value total

Output R-CT [9.1] DPT_Value_Temp 2 Bytes

24 Temperature sensor: meas-

ured value min./max. query

Input -WC- [1.17] DPT_Trigger 1 Bit

25 Temperature sensor: meas-

ured value minimum

Output R-CT [9.1] DPT_Value_Temp 2 Bytes

26 Temperature sensor: meas-

ured value maximum

Output R-CT [9.1] DPT_Value_Temp 2 Bytes

27 Temperature sensor: meas-

ured value min./max. reset

Input -WC- [1.17] DPT_Trigger 1 Bit

30 Temp. thresholdV 1: Absolute

value

Input /

Output

RWCT [9.1] DPT_Value_Temp 2 Bytes

31 Temp. thresholdV 1: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 Bit

32 Temp. thresholdV 1: Switching

delay from 0 to 1

Input -WC- [7.5] DPT_TimePeriod-

Sec

2 Bytes

33 Temp. thresholdV 1: Switching

delay from 1 to 0

Input -WC- [7.5] DPT_TimePeriod-

Sec

2 Bytes

34 Temp. thresholdV 1: Switching

output

Output R-CT [1.1] DPT_Switch 1 Bit

35 Temp. thresholdV 1: Switching

output block

Input -WC- [1.1] DPT_Switch 1 Bit

36 Temp. thresholdV 2: Absolute

value

Input /

Output

RWCT [9.1] DPT_Value_Temp 2 Bytes
