5. OVERVIEW OF THE TONVERK STRUCTURE

19

5. OVERVIEW OF THE TONVERK STRUCTURE

The illustration below outlines the Tonverk structure.

128 PATTERNS

PROJECT

SAMPLES

4 GB

SD CARD

Projects, Presets, Samples

16 SONGS

16 TRACKS

5.1 SD CARD

The SD card contains Tonverk data, where Projects, Presets, Instruments, Samples, and global settings

are stored. The amount of data you can store on the SD card depends on the size of the SD card. Tonverk

comes with a 64 GB SD card. The recommended minimum card size is 2 GB, and it must be formatted in

exFAT format. For more information, please see “6.11 SAMPLE BROWSER” on page 24.

5.2 DATA STRUCTURE

5.2.1 PROJECT

A project contains 128 patterns. The project also stores general settings and states. The currently loaded

project becomes the active working state of Tonverk. From here, it is possible to edit the patterns and

presets of the project. Every time Tonverk is switched on, it boots to the active working state, the active

project. Projects are saved, loaded, and managed in the FILE menu. For more information, please see “9.1

THE FILE MENU” on page 31.

5.2.2 SONGS

A song is an arrangement of patterns set up to play in sequence. Each row in the SONG mode arrange-

ment can have separate settings for pattern, row repeat, row length, and tempo. A song can be up to

99 rows in length, and each project can contain up to 16 songs. For more information, please see “10.11

SONG MODE” on page 43.

5.2.3 PATTERNS

The patterns are the primary data container for Tonverk. Sixteen patterns are available for each of the

eight banks, resulting in 128 patterns for each project. A pattern contains up to 12 presets (one for each

audio or MIDI track), plus sequencer data like trigs and parameter locks. It also includes the settings on

the TRIG page, as well as BPM, length, swing, and time signature settings. For more information, please

see “10. THE SEQUENCER” on page 35.

5.2.4 SAMPLES

Tonverk can load and play WAV and AIFF audio files (samples) with 16/24/32-bit depth (floating and fixed

point) and a sample rate of 48 kHz (mono and stereo interleaved). Files with other sample rates (44.1 kHz/

88.2 kHz/96 kHz) can also be loaded, but they will gracefully degrade in quality when played back. You

can load up to 4 GB of samples in a project’s internal memory, using a maximum of 1023 sample slots.

Samples are stored on the SD card, and the size and number of those samples are limited only by the

available free space on the SD card. For more information, please see “9. PATTERNS, PRESETS, IN-

STRUMENTS AND SAMPLES” on page 31.

All samples that are played on a track in Tonverk are played back with an attenuation (low-

ering of volume) of -22dB to maintain headroom in the device. The sample files themselves

are unaected.

5.3 MACHINES AND TRACKS

The Tonverk sequencer has 16 tracks. 8 Audio/MIDI tracks, 4 Bus and MIDI tracks, 3 Send FX tracks, and

one Mix track.
