22
Installation manual
mm
inch
A B C D E F G H
EUD-615 495
19 1/2
460
18 1/8
110
4 5/16
125
4 15/16
375
14 3/4
170
6 11/16
40
1 9/16
100
3 15/16
EUD-618 495
19 1/2
460
18 1/8
110
4 5/16
125
4 15/16
375
14 3/4
170
6 11/16
40
1 9/16
100
3 15/16
EUD-625 575
22 5/8
465
18 5/16
130
5 1/8
140
5 1/2
455
17 15/16
185
7 5/16
35
1 3/8
95
3 3/4
EUD-630 635
25
490
19 5/16
135
5 5/16
175
6 7/8
515
20 1/4
195
7 11/16
65
2 9/16
125
4 15/16
EUD-645 715
28 1/8
545
21 7/16
125
4 15/16
205
8 1/16
595
23 7/16
185
7 5/16
65
2 9/16
125
4 15/16
EUD-660 790
31 1/8
615
24 3/16
115
4 1/2
180
7 1/16
670
26 3/8
175
6 7/8
65
2 9/16
125
4 15/16
EUD-680 900
35 7/16
835
32 7/8
60
2 3/8
140
5 1/2
670
26 3/8
175
6 7/8
60
2 3/8
80
3 1/8
Place the machine over the two drilled holes. The holes are at the front of the machine.
Level the machine with the feet of the machine. Screw in the feet as much as possible before starting to level the ma-
chine. This will make the machine stand steadier.
The maximum height adjustment of the feet is 30 mm / 1 3/16 inch for EUD-615, EUD-618, EUD-625 and 50 mm / 1
15/16 inch for EUD-630, EUD-645, EUD-660, EUD-680.
Insert the expansion bolts (1) into the holes drilled in the floor. Fit the washers and nuts and tighten with tightening
torque 5 Nm / 3.7 lbf.ft.
It is of the upmost importance that the machine is placed in level, from side to side as well as front to rear.
Remount the panels when ready.
