Installation manual
23
5 Water connection
All water intake connections to the machine should be fitted with manual shut-off valves and filters, to facilitate instal-
lation and servicing.
Water pipes and hoses should be flushed clean before installation.
The machine shall be connected with new water hoses. Re-used water hoses must not be used.
Hoses are to be of an approved type and grade and comply with national regulations.
After installation hoses must hang in gentle arcs.
All connectors present on the machine must be connected to the water supply or the machine may not func-
tion properly. The table shows the possible connection options, which will depend on the water types to be con-
nected to the machine. Information is also available on the panel above the connections.
Note!
The water supply should be within the recommended hardness range of 3 grains or less per gallon. Higher
hardness may cause excessive formation of limescale. Chlorides must not exceed 30 ppm. The buildup of
limescale will negatively affect operation, performance and warranty approval.
Water type Water connection
1
2
EUD-615, EUD-618, EUD-625
• Cold and hot
EUD-615, EUD-618, EUD-625
1. Cold (for detergent dispenser)
2. Hot
1
2
3
EUD-630, EUD-645, EUD-660, EUD-680
• Cold and hot
EUD-630, EUD-645, EUD-660, EUD-680
1. Cold
2. Hot
3. Cold (for detergent dispenser) / Hot
There is also an extra water valve which can be used for hard water if soft water is connected to 1.
This valve can also be used for water re-use from tank.
If pump is used, it is only a water connection without valve.
Water pressure:
Continuous operating pressure: 50–800 kPa / 8–116 psi (0.5-80 kp/cm
2
)
Maximum: 1000 kPa / 145 psi (10 kp/cm
2
)
Recommended: 200–600 kPa / 30–90 psi (2–6 kp/cm
2
)
Recommended water hardness: 3 grains per gallon
Recommended pH-range: 7.0–8.0
Acceptable range for chloride concentration: 0–30 ppm
Note!
If the water pressure is below the minimum value, the wash result can not be guaranteed for certain program.
