24 en | Amplifier DSP ZLX-G2 Full-range loudspeaker
2024-03 | 02 |
User manual
Bosch Security Systems, LLC
– MONITOR - is used when the loudspeaker is placed on the angled monitor panel in
monitor position. This setting compensates for the amount of low frequency boost
created by placing the loudspeaker on a level and stable flat surface.
– WALL - is used when the loudspeaker is mounted to the wall using the mounting
bracket (mounting bracket accessory sold separately). This setting compensates for the
amount of low frequency boost created by placing the loudspeaker close to the wall.
The default is TRIPOD.
SUB menu
The SUB menu is used to select a high pass frequency for use with a subwoofer.
Available options for this selection are: OFF, 80Hz, 100Hz, 120Hz, 150Hz, ELX118SP,
ETX-15SP, ETX18-SP, 80Hz, and ZXA1-SUB. The 100Hz, 120Hz, and 150Hz choices are
generic high pass settings for use with other subwoofers. The ELX200-12SP, ELX200-18SP,
EKX-15SP and EKX-18SP settings are specifically optimized for subwoofers by including
delay for best summation.
The default is OFF.
TREBLE control
The TREBLE control is used to adjust the high frequency performance of the loudspeaker for
different applications or personal preference. The parameter controls a high shelving filter.
The default is 0dB.
MID control
The MID control is used to adjust the midrange frequency performance of the loudspeaker
for different applications or personal preference.
The default is 0dB.
BASS control
The BASS control is used to adjust the low frequency performance of the loudspeaker for
different applications or personal preference. The parameter controls a low shelving filter.
The default is 0dB.
MAIN GEQ menu (default)
The MAIN GEQ menu is used to adjust the frequency response of the loudspeaker for
different applications or personal preference. There are seven different EQ filters available
centered at the following frequencies: 63, 160, 400, 1.0K, 2.5K, 6.0K & 12K Hz.
The range of each filter is -12dB to +12dB.
The default value for each filter is 0dB.
MAIN PEQ menu
The MAIN PEQ is used to adjust the frequency response of the loudspeaker for different
applications or personal preference. There are seven equalization filters available.
The filter type is selectable between the following:
PEQ - Parametric Equalization Filters shape the sound using peak/dip bell shaped filters
which have three controls.
– Q - Quality Factor defines the bandwidth width of the filter. A lower Q provides a wider
bandwidth and a higher Q provides a narrower bandwidth.
– FREQ - selects the center frequency of the EQ filter.
