www.elationlighting.com
20 RAYZOR Q12 ZOOM™ User Manual ver 1
INFORMATION - Time Information - Current Time
Displays fixture run time from last power ON.
The counter is reset after each time the fixture is powered OFF.
INFORMATION - Time Information - Total Run Time
Displays fixture total run time.
INFORMATION - Time Information - Last Run Time
Displays fixture run time for a given period of time (i.e. rental period).
This counter can be reset.
INFORMATION - Time Information - LastRun Password
Display the fixture timer password. (038)
INFORMATION - Time Information - Clear Last Run
Resets the last run time of the fixture.
INFORMATION - Temperature Information - Head Temperature
Displays temperature of the fixture.
INFORMATION - Software Version
Displays software version of the fixture.
PERSONALITY - Status Settings - Address Via DMX
When ON, define the desired DMX address via an external controller.
1. Connect the fixture to the external controller and power ON.
2. Set the DMX value of Channel 1 on the controller to (7).
3. Set the DMX value of Channel 2 on the controller to (7) or (8).
When set to (7), the DMX address can be set between (1) and (255).
When set to (8), the DMX address can be set between (256) and (511).
4. Using Channel 3 on the controller set the desired DMX address of the fixture.
Example 1:
If the desired DMX address is 57, set Channel 1 to a value of (7), set Channel 2 to
a value of (7), and then set Channel 3 to a value of (57).
Example 2:
If the desired DMX address is 420, set Channel 1 to a value of (7), set Channel 2 to
a value of (8), and then set Channel 3 to a value of (164). (256+164=420)
5. After setting Channel 3 to the desired DMX address value, wait for approximately
20 seconds for the fixture to complete the address reset function.
