www.elationlighting.com
19 RAYZOR Q12 ZOOM™ User Manual ver 1
ELATION© RAYZOR Q12 ZOOM™
S Y S T E M M E N U
Specifications are subject to change without any prior written notice.
MAIN MENU
SUB MENU
OPTIONS / VALUES
(Default Settings in BOLD)
DESCRIPTION
User Mode Set
User Mode
Stand Mode
DMX Channel Modes Basic Mode
Extend Mode
User Mode A
User Defined Channel Assignment
User Mode B
User Mode C
Edit User Mode
Max Channel = XX
Edits User Defined
Channel Assignments
PAN = CH01
Edit Program
Select Programs
Auto Pro Part1 = Program 1~10 (Program
1)
Select Programs To Be Run
Auto Pro Part2 = Program 1~10 (Program
2)
Auto Pro Part3 = Program 1~10 (Program
3)
Edit Program
Program 1
Program Test
Testing Program
: Step 01=SCxxx Program In Loop
Program 10
Step 64=SCxxx
Save and Exit
Edit Scenes
Scene 001
~
Scene 250
Pan,Tilt,…… Save and Automatically Return
--Fade Time--
--Scene Time--
Manual Scenes Edit
Input By Outside
Stores Scenes via Ext DMX Console
Record Controller XX~XX Automatic Scenes Recorder
FUNCTION - Set DMX Address
Define desired DMX address via the Control Panel.
FUNCTION - DMX Value
Display DMX 512 value of each channel.
FUNCTION - Slave Mode
Define fixture slave mode (Slave1, Slave2, Slave3).
FUNCTION - Auto Program
Define fixture mode (Master or Alone) for running Auto Programs. Select desired
internal programs under “Select Program”, set the number of steps under “Edit
Program”, and edit individual scenes under “Edit Scenes”.
FUNCTION – Sound Control
Define fixture mode (Master or Alone) for running Auto Programs via sound
activation, default is Master.
