LIGHTING CONSOLE PATCHING GUIDELINES
CATEGORY GROUP PIXELS
RGBW Pixel Columns
Column 1 8
Column 2 4, 13
Column 3 1, 9, 17
Column 4 5, 14
Column 5 2, 10, 18
Column 6 6, 15
Column 7 3, 11, 19
Column 8 7, 16
Column 9 12
RGBW Pixel Rows
Row 1 1 - 3
Row 2 4 - 7
Row 3 8 - 12
Row 4 13 - 16
Row 5 17 - 19
RGBW Pixel Rings
Ring 1 1, 2, 3, 7, 12, 16, 19, 18, 17, 13, 8, 4
Ring 2 5, 6, 11, 15, 14, 9
Ring 3 10
Spark LED Rows
Row 1 1 - 3
Row 2 4 - 9
Row 3 10 - 16
Row 4 17 - 24
Row 5 25 - 33
Row 6 34 - 43
Row 7 44 - 52
Row 8 53 - 60
Row 9 61 - 67
Row 10 68 - 73
Row 11 74 - 76
Spark LED Rings
Ring 1
1, 2, 3, 9, 16, 24, 33, 43, 52, 60, 67, 73, 76, 75, 74,
68, 61, 53, 44, 34, 25, 17, 10, 4
Ring 2
5, 6, 7, 8, 15, 23, 32, 41+42, 51, 59, 66, 72, 71, 69,
70, 62, 54, 45, 35+36, 26, 18, 11
Ring 3 13, 14, 22, 31, 50, 58, 65, 64, 63, 55, 46, 27, 19, 12
Ring 4 20, 21, 3, 40, 49, 57, 56, 47, 37, 28, 20
Ring 5 29, 39, 48, 38
