32
There are also two additional parts for a primary control of the PROTEUS RAYZOR 1960,
which creates four separate control areas for the xture. It is recommended to create xture
groups on the lighting controller for each area of the xture. (see below)
Main Fixture Primary Pan, Tilt, RGBW Color, Strobe, Dimmer, Zoom, FX Controls
RGBW Cells 1-19 Red, Green, Blue, White per each individual cell
Spark LED Main Primary Spark LED Strobe, Dimmer
Spark LEDs 1-76 Spark LED Dimmer per each individual LED
SparkLED is not available as a mode in the xture menu but must be provided as a console
control prole for easy programming of the xture. Use the PROTEUS RAYZOR 1960 in
Extended mode and patch appropriate parts of the RGBW Pixels and SparkLED xtures on
your control system to access all 176 channels.
On the lighting controller, patch the two xture types (RGBW and SparkLED), separating the
SparkLEDs into a dierent ID range. (see below)
RGBW Pixels for Channels 1-98
SparkLEDs for Channels 99-176
ONYX Main and Sub Fixture ID patch example below for a single PROTEUS RAYZOR 1960 x-
ture.
ID TYPE ADDRESS
1.0 RGBW Pixels Main 1
1.1 Pixel 1 22
1.2 Pixel 2 26
1.3 Pixel 3 30
1.4 Pixel 4 34
1.5 Pixel 5 38
... ... ...
1.19 Pixel 19 94
1.20 Spark LED Main 98
101.1 Spark LED 1 101
101.2 Spark LED 2 102
101.3 Spark LED 3 103
101.4 Spark LED 4 104
... ... ...
101.76 Spark LED 76 176
LIGHTING CONSOLE PATCHING GUIDELINES
