ELATION E SPOT III™
DMX Channel Values / Functions Version 1 - (20 DMX Channels)
Specifications are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of COLOR, GOBO, and PRISM effects depends on orientation of the fixture head.
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
5
7
8
ROTATING GOBOS, INDEX ROTATION [GOBO WHEEL 1]
0-127
Gobo Indexing
128-189
*Clockwise Gobo Rotation from FAST TO SLOW
190-193
NO Rotation
194-255
*Counterclockwise Gobo Rotation from SLOW to FAST
9
ROTATING GOBOS, FINE INDEX ROTATION [GOBO WHEEL 1]
0-255
Gobo Rotation FINE Indexing
6
8
10
FROST, TRAPEZOID & 3-FACET ROTATING PRISMS / MACROS
0-31
OPEN
32-63
3-FACET Prism
64-95
LINEAR Prism
96-127
FROST
128-135
Prism / Gobo Macro 1
136-143
Prism / Gobo Macro 2
144-151
Prism / Gobo Macro 3
152-159
Prism / Gobo Macro 4
160-167
Prism / Gobo Macro 5
168-175
Prism / Gobo Macro 6
176-183
Prism / Gobo Macro 7
184-191
Prism / Gobo Macro 8
192-199
Prism / Gobo Macro 9
200-207
Prism / Gobo Macro 10
208-215
Prism / Gobo Macro 11
216-223
Prism / Gobo Macro 12
224-231
Prism / Gobo Macro 13
232-239
Prism / Gobo Macro 14
240-247
Prism / Gobo Macro 15
248-255
Prism / Gobo Macro 16
7
9
11
TRAPEZOID & 3-FACET ROTATING PRISM, INDEX ROTATION
0-127
Prism Indexing
128-189
*Clockwise Linear Prism Rotation from FAST to SLOW
190-193
NO Rotation
194-255
*Counterclockwise Linear Prism Rotation from SLOW to FAST
12
TRAPEZOID & 3-FACET ROTATING PRISM, FINE INDEX ROTATION
0-255
Prism FINE Indexing
8
10
13
FOCUS
0-255
Continuous Adjustment from FAR to NEAR
9
11
14
SHUTTER, STROBE
0-31
Shutter CLOSED
32-63
NO Function (Shutter OPEN)
64-95
Strobe Effect SLOW to FAST
96-127
NO function (Shutter OPEN)
128-159
Pulse Effect In Sequences
160-191
NO Function (Shutter OPEN)
192-223
Random Strobe Effect SLOW to FAST
224-255
NO Function (Shutter OPEN)
