DMX CHANNEL FUNCTIONS AND VALUES
ELATION E SPOT III™
DMX Channel Values / Functions Version 1 - (20 DMX Channels)
Specifications are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of COLOR, GOBO, and PRISM effects depends on orientation of the fixture head.
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
1
1
1
PAN MOVEMENT [8 BIT]
0-255
PAN Movement 630°/540°
2
2
PAN FINE MOVEMENT [16 BIT]
0-255
Fine Control of PAN Movement
2
3
3
TILT MOVEMENT [8 BIT]
0-255
TILT Movement 270°
4
4
TILT MOVEMENT [16 BIT]
0-255
Fine Control of TILT Movement
3
5
5
COLOR WHEEL
0-14
OPEN / WHITE
15-29
RED
30-44
BLUE
45-59
GREEN
60-74
YELLOW
75-89
MAGENTA
90-104
ORANGE
105-119
LIGHT BLUE
120-127
PINK
128-189
*Clockwise Color Wheel Rotation from FAST to SLOW
190-193
NO Rotation
194-255
*Counterclockwise Color Wheel Rotation from SLOW to FAST
6
COLOR WHEEL FINE ADJUSTMENT
0-255
FINE Adjustment of Color Wheel to Any Position
4
6
7
ROTATING GOBOS, CONTINOUS ROTATION
0-9
OPEN
10-19
Rotating Gobo 1
20-29
Rotating Gobo 2
30-39
Rotating Gobo 3
40-49
Rotating Gobo 4
50-59
Rotating Gobo 5
60-69
Rotating Gobo 6
70-79
Rotating Gobo 7
80-89
Gobo 1 Shake SLOW to FAST
90-99
Gobo 2 Shake SLOW to FAST
100-109
Gobo 3 Shake SLOW to FAST
110-119
Gobo 4 Shake SLOW to FAST
120-129
Gobo 5 Shake SLOW to FAST
130-139
Gobo 6 Shake SLOW to FAST
140-149
Gobo 7 Shake SLOW to FAST
150-199
*Clockwise Gobo Wheel Rotation from FAST to SLOW
200-205
NO Rotation
206-255
*Counterclockwise Gobo Wheel Rotation from SLOW to FAST
