22
ELATION E SPOT III™
DMX Channel Values / Functions Version 1 - (20 DMX Channels)
Specifications are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of COLOR, GOBO, and PRISM effects depends on orientation of the fixture head.
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
10
12
15
DIMMER INTENSITY
0-255
Intensity 0 to 100%
16
DIMMER INTENSITY FINE
0-255
Dimmer Intensity FINE Adjustment
11
13
17
DIMMING MODE
0-20
Standard
21-40
Stage
41-60
TV
61-80
Architectural
81-100
Theatre
101-255
Default to Unit Setting
12
14
18
IRIS
0-191
MAX to MIN Diameter
192-223
Pulse Closing FAST to SLOW
224-255
Pulse Opening SLOW to FAST
13
15
19
PAN / TILT MOVEMENT SPEED
0-225
MAX to MIN Speed
226-235
Blackout with PAN and TILT Movement
236-245
Blackout with ALL Wheel Movement
246-255
NO Function
14
16
20
SPECIAL FUNCTIONS
0-19
Color & Gobo Change Normal
20-29
Color Change to Any Position
30-39
Color & Gobo Change to Any Position
40-59
NO Function
60-79
NO Function
80-84
ALL Motor Reset
85-87
PAN & TILT Motors Reset
88-90
COLORS Motor Reset
91-93
GOBOS Motor Reset
94-96
NO Function
97-99
OTHER Motors Reset
100-119
Internal Program 1 (Scene 1-8)
120-139
Internal Program 2 (Scene 9-16)
140-159
Internal Program 3 (Scene 17-24)
160-179
Internal Program 4 (Scene 25-32)
180-199
Internal Program 5 (Scene 33-40)
200-219
Internal Program 6 (Scene 41-48)
220-239
Internal Program 7 (Scene 49-56)
240-255
NO Function
