12
and a car with horizontal load ,the maximum load capacity Q [kg]
In the corresponding lifting height of the truck H [mm],The white
markings on the frame indicate the range of lift that can be achieved.
For example, a cargo's center of gravity distance c is 600mm, the
maximum lifting height H is 6000mm, and the maximum load capacity
Q is 500kg.
8.3Lifting up
Pls don’t overload, The related capacity is 1500KG .Only increase the load
capacity allowed by the load capacity graph
Please lower the fork completely on the leg during driving .Then press lift up button(Figure
7.3)until reach your desired height .
8.4Lifting down
If the fork is on the shelf when lifting down, Remove the carefully with the pallet rack or move
the car off the shelf separately ,Then press lift down key(Figure7.3) Lower the cargo until the
fork left the pallet rack .then carefully drive the car away from the cargo
8.5Fork move forward /backward
Push the lever forward (Figure 7.2) and the fork move t forward.
Pull back on the lever (Figure 7.2) and the fork move backwards.
8.6Fork titling forward /backward
Push the tilt lever forward (Figure 7.1) and the fork tilt forward.
Pull the tilt lever back (Figure 7.1) and the fork tilt backwards.
8.7Traveling
Only drive on the slope when the cargo are facing up
Don’t drive on the slope in excess the specified specifications .
Only can driving when the fork falls to the lifting point (<300mm)
！
！
