16
Drilling
Inclined drilling
▪ Remove the screw that locks
the drill column at 90°.
▪ Then loosen the two M10 he-
xagon socket screws using
the SW8 wrench provided.
▪ Move the column to the desi-
red angle. Tighten the two
screws again.
▪ After drilling, return the co-
lumn to the 90° position and
lock it in place with the screw.
On the BST 300, the toggle screw
located on the support must also
be loosened.
The scale on the tooth column
makes it easier to set the drilling
angle, which greatly simplifies the
work.
At the beginning, it is important to drill very slowly, as only a fraction of the
cutting surface of the core bit engages with the material. Drilling too quickly
or with too much pressure can cause the core bit to slip.
An extension may be required for the core bit in order to achieve the full
drilling depth!
Demounting the Core Drill Unit
▪ Move the machine holder with the core drilling machine upwards until it
locks into the end position.
▪ Remove the drill bit.
▪ Loosen the wing nut (F). (see section on fastening)
▪ Hold the drill stand firmly in place while doing so!
▪ Remove the drill stand.
▪ Unscrew the quick-release screw (D). (see section on fastening)
