14
Fastening by means of quick action bracing unit
In order to be able to brace the drill stand using the quick-release co-
lumn, the distance to the opposite wall must be between 1.7 m and 3 m.
Position the drill stand. Place the quick-release column
as close as possible behind the column on the stand
base. Secure the drill stand by turning the crank (G)
clockwise. Secure the setting with the corresponding
bolt (H).
Caution!
It is important that the drill stand is firmly secured to the ground. Incor-
rectly secured drill stands can cause injury to the operator and dam-
age to the drill unit.
Movements during drilling cause the drill bit to strike the borehole
wall, which can lead to the segments breaking off. The drill bit can also
become jammed in the borehole, which in turn causes damage to it.
Fixing the Core Drill Motor
Be careful when inserting the machine, risk of crushing!
Wear protective gloves!
Setting up the mounting plate
Move the machine holder upwards until it
locks into place.
Use the turnstile to open the mounting
plate lock.
Remove it and connect it to the core
drilling machine as described below.
