16
Drilling
At the beginning, drill very slowly, since the drill bit does only starts cutting with a
fraction of the cut surface in the material. If you drill too fast or with too much
pressure, the drill bit could get jammed.
Observe the LED in the handle of the ESD 162. If it lights red, reduce your
pressing force.
Angled drilling
Loosen the two side screws (1) on the base
plate.
Loosen the clamp (2) on the support with the
help of the feed lever.
Now turn the column until the desired angle.
Tighten the 2 screws (1) and the clamp (2)
again.
The scale on the toothed column makes adjusting
the drilling angle easier.
Demounting the core drill unit
Move the machine holder with the core drill upwards and fix it by tightening
the screw (1 - page 14).
Remove the drill bit.
Loosen the clamping screw at the machine holder and remove the core drill
machine from the drill rig. (see page 14)
Loosen the fastening nut (F). (see page 13)
While doing so, hold the drill rig firmly!
Remove the drill rig.
Unscrew the quick action clamping screw (D). (see page 13)
Care and maintenance
Always keep the drill rig clean, especially the column with the toothing and
the 4 sliding rollers in the machine holder. In order to allow the free
movement of the pinion shaft, it should be slightly lubricated.
2
1
