17
In order to achieve a good performance of the drill rig, the 4 sliding rollers in
the machine holder have to move along the column without slackness.
Attention!
After every tenth drilling you should check if the sliding pieces
have got
loose
-
fitting due to drilling vibration.
If the position has changed, it can be adjusted as follows:
Use an open-ended spanner SW 19 to loosen the nut on the sliding roller marked
E.
By slightly turning the nuts (K) with an open-ended spanner SW 19, the pressure
of the sliding roller can be adjusted.
After adjusting the sliding roller, the nut (I) must be tightened again.
Behaviour at malfunction
Turn off the machine by malfunction and disconnect from the
electricity network. Operations on the electrical system of the
machine can be executed only by a specialist.
Trouble shooting
M
alfunction
P
ossible cause
R
epair
Drill unit has too
much play
(vibration)
stand has been loose
guidance has too much play
thrust piece worn
thrust sliding rollers
adjust the wing nut
adjust guidance (see page 16)
replace the thrust piece
replace the sliding rollers
I
K
