ADLN-I USER MANUAL
4
Table of Motherboard Components
LABEL COMPONENTS
1. SoC Onboard Intel® Alder Lake-N Series
2. TPM Trusted platform module header
3. SATA1~2 Serial ATA 6Gb/s connectors
4. F_PANEL Front panel switch/LED header
5. COM2 Onboard serial port header
6. CASE CASE open header
7. LPT Onboard parallel port header
8. BZ1 Buzzer
9. SATA_PWR 15 pin SATA Power header
10. SYS_FAN 4-pin system cooling fan connectors
11. CPU_FAN 4-pin CPU cooling fan connector
12. DIMM1~2 228-pin DDR4 SDRAM SO-DIMM
13. CLR_CMOS Clear CMOS jumper
14. BT Battery
15. ATX_POWER Standard 24-pin ATX power connector (Opt.)
16. FUSB1~2 Front panel USB 2.0 headers
17. M.2_1 Support Type KEY M 2280 PCIE x1 / SATA p6-x1 Gen3 SSD
18. F_AUDIO Front panel audio header
19. SPKR Speaker Header
20. M.2_WLAN M.2 2230 KEY E for WiFi/BT supports CNVi
21. USB3F Front panel USB 3.2 Gen1 p6-x1 header
