12
PRECAUTIONS
WARRANTY
&
ENVIRONMENT
DESCRIPTION
&
FEATURES
WiLD DECT
TECHNOLOGY
INSTALL
&
CONNECT
PAIRING &
STARTING UP
PACKAGE
CONTENTS
LED
INDICATORS
TECHNICAL
DATA
PANEL
FUNCTIONS
6. INSTALL & CONNECT
6.1 WiLD-14 Receivers
The WiLD-14 receivers come with the lighting rail bracket already mounted.
Follow these steps to install a WiLD-14 unit in a lighting rail:
1. Ensure that the 4-position (OFF-1-2-3) circuit selector wheel in the WiLD-14 unit is in
the OFF position.
2. Insert the loudspeaker in the lighting rail, as shown in the image
Connection to a GLOBAL Trac Pro / Eutrac lighting rail (three-circuit lighting track system)
3. Rotate the safety lug to secure the loudspeaker on the lighting rail. Rotate the circuit
selector wheel to a position other than OFF, the one matching with a circuit in the rail that
will deliver mains AC to the unit. Then, the safety lug will be locked
