Description
Enabled Enable hotspot (LAN)
Routing Only for advanced user
Define the NAT configuration, it’s possible to do a port forwarding to another interface via this
feature.
The options available depends of the "Mode" and are:
Uplink (to internet)
The uplink port is part of a network, possibly connected to the Internet, and this option:
Allows network and internet sharing with Downlink ports.
Downlink (to node)
The downlink port manages a subnet with other nodes, and this option:
Routes sub-network traffic to Uplink ports.
Changes default fixed address to avoid conflicts.
Keeps the port active beyond commissioning period.
Mode Only for advanced user
DHCP server: network server that automatically provides and assigns IP addresses, default
gateways and other network parameters to client devices.
DHCP client: this is the endpoint receiving DHCP server configuration information.
Fixed address: to use for fixed IP address
The default setting is Fixed address.
SSID SSID is an abbreviation for service set identifier, which is an important identifier for wireless
networks. Essentially, an SSID is the name assigned to a Wi-Fi network.
Password Password to connect the Wi-Fi hotspot
Security WPA2 PSK
This is the minimal security requirement.
Country NA
IP IPv4 address in the local network
Default: 192.168.53.1
Mask Mask for the subnetwork
Default: 255.255.255.0
Gateway IPv4 address to the modem / router
Default: empty
DNS IPv4 address to the modem / router DNS service
Default: empty
Description
Enabled Enable Wi-Fi connection
Routing Only for advanced user
Define the NAT configuration, it’s possible to do a port forwarding to another interface via this
feature.
The options available depends of the "Mode" and are:
Uplink (to internet)
The uplink port is part of a network, possibly connected to the Internet, and this option:
Allows network and internet sharing with Downlink ports.
Downlink (to node)
The downlink port manages a subnet with other nodes, and this option:
Routes sub-network traffic to Uplink ports.
Changes default fixed address to avoid conflicts.
Keeps the port active beyond commissioning period.
SSID SSID is the network name the charging station will connect. Click Scan button to fill the list of
SSID with the available Wi-Fi Networks
Password Password to connect the Wi-Fi network
Mode Only for advanced user
DHCP server: network server that automatically provides and assigns IP addresses, default
gateways and other network parameters to client devices.
DHCP client: this is the endpoint receiving DHCP server configuration information.
Fixed address: to use for fixed IP address
The default setting is Fixed address.
Table 24. Wi-Fi Connection
Table 25. Wi-Fi Hotspot (Advanced user only)
64
GREEN MOTION BUILDING INSTALLATION MANUAL MN191028EN April 2024 www.eaton.com
