6.5.4 Current settings for EV-ready compliance
To be EV-ready compliant, one of the requirements for an EV charger is that it can provide minimum charging current
to the vehicle. The installer must ensure that the EV charger’s maximum current limit settings (via DIP switch) respect
the EV-ready minimum current requirements.
Please refer to Table 13 for the maximum current settings applicable to an EV-ready installation.
In the event of damage caused by improper current adjustment, the product warranty is void and no returns will
be accepted. Eaton disclaims any responsibility for improper current adjustment and cannot be held liable for an
inappropriate operation.
Table 13. Switch settings for EV-ready compliance
Green Motion Building.
version: 22 kW (1P)
Green Motion Building.
version: 22 kW (3P)
DIP switch
OK OK
OK OK
OK OK
OK OK
41GREEN MOTION BUILDING INSTALLATION MANUAL MN191028EN April 2024 www.eaton.com
