ASSEMBLY INSTRUCTIONS

16410 / 16457

Dear Customer,

We are delighted that you have chosen the EASYmaxx telescopic insect screen 'swing door'. Before using the product for the ﬁrst time, please read

through the assembly instructions carefully and store them in a safe place. If you have any questions, contact the customer service department via our

website: www.ds-group.de/kundenservice

IMPORTANT NOTICES

■ The product is suitable for use as an insect screen door on door frames

(fordimensions, see the “Product data” chapter).

■ The product is for personal use only and is not intended for commercial

applications.

■ Use the product only for the intended purpose and as described in the

operating instructions. Any other use is deemed to be improper.

■ Keep the packaging material away from children and animals. There is

adanger of suffocation!

■ The product is not a toy! Children must be supervised in order to ensure

that they donot play with the product.

■ Protect the product from ﬁre and sharp and pointed objects.

■ Do not use any caustic or abrasive cleaning agents. If necessary, wipe with

a damp cloth and mild cleaning agent.

ITEMS SUPPLIED

A Mosquito net (frame incl. net), 2 x

B Telescopic rod, 1 x

C Rubber seal (approx. 142 cm), 1 x

D Connector (ﬂat), 1 x

E Connector (with magnet and recessed handles), 1 x

F Door mount, self-adhesive (centre), 1 x

G Door mount, self-adhesive (corner); 1 x top, 1 x bottom

H Brush seal (self-adhesive approx. 800 cm), 1 x

I Axle module lock, 3 x (2 x of these are spare)

J Axle module, 3 x

K Screw, 8 x

L Allen key, 1 x

M Magnet, self-adhesive (round), 2 x

N Metal plate, self-adhesive (round), 2 x

O Frame lock, 8 x

P Door mount, self-adhesive (bottom), 1 x

Q Metal plate, self-adhesive (oblong), 1 x (not shown)

• Assembly instructions, 1 x

Check the items supplied for completeness and the components for transport

damage. If you ﬁnd any damage, do not use the product but contact our customer

service department.

2 x

1 x

3 x

8 x8 x

2 x2 x

8 x8 x

1 x1 x

1 x

PRODUCT DATA

Article number:

16410 (anthracite)

16457 (white)

Model number: JHK-16018B

Dimensions (W x H):

– Portrait format:

– Landscape format:

min. approx. 73 x 168 cm / max. approx. 120 x 280 cm

min. approx. 83 x 168 cm / max. approx. 140 x 240 cm

Required window frame

width: ≥ 5 cm

ID of operating instructions:

Z 16410_16457 M DS V2 0825 as

DISPOSAL

Dispose of the packaging material in an environmentally friendly

manner so that it can be recycled.

Waste prevention makes an even more valuable contribution to protecting

the environment. This means if possible, as well as continuing to use or

repair a product yourself, passing it on to another user also represents an

ecologically beneﬁcial alternative to disposal.
