Troubleshooting
Operating Instructions D867 e-con - 00.0 - 06/2023 219
2173 Error Stepper card X30 sewing
motor encoder not connected
(Stitch length)
• Replace the control
2174 Error Stepper card X30 sewing
motor encoder not initialized
(Stitch length)
• Perform software update
• Check selection of class
2175 Error Stepper card X30 init position
not found (Stitch length)
• Check for stiff movement
• Replace encoder
• Replace motor
2176 Error Stepper card X30 not
enabled (Stitch length)
• Replace the control
2177 Error Stepper card X30 overload
(Stitch length)
• Check for stiff movement
• Replace encoder
• Replace motor
2178 Error Stepper card X30 encoder
failure (Stitch length)
• Replace encoder
2179 Error Stepper card X30 current
sensor failure (Stitch length)
• Replace the control
2180 Error Stepper card X30 incorrect
stepping motor direction of
rotation (Stitch length)
• Replace encoder
• Check if plugs have been mixed up
• Check the wiring in the machine distribu-
tor and change it if necessary
2181 Error Stepper card X30 reference
drive failure (Stitch length)
• Check for stiff movement
• Replace encoder
• Replace motor
2183 Error Stepper card X30 overcurrent
(Stitch length)
• Replace the control
2184 Error Stepper card X30 parameter
initialization (Stitch length)
• Perform software update
• Check selection of class
2185 Error Stepper card X30 insulation
error (Stitch length)
• Check motor phase and PE for low-
impedance connection
• Replace encoder
• Replace sewing motor
Code Type Possible cause Corrective
