9
DRAWMER 1971 OPERATOR’S MANUAL
LOW-MID
FREQUENCY: 60Hz - 2.1kHz
See 3
BANDWIDTH: 0.33 - 3.3 Octaves
Bandwidth is dened as the range of frequencies (width) centred
around that set by the frequency knob allowing you to attenuate or
boost a very narrow or wide range of frequencies within each EQ
band.
On the 1971 the width of the eected signal is measured as Bandwidth
(as opposed to ‘Q’, which it is inversely related to) and on the Low-Mid and High-Mid bands are fully parametric
(as opposed to semi, quasi or xed that you may nd on other eq’s) meaning that the bandwidths are fully
adjustable across their entire range providing greater control.
CUT/BOOST: -12dB - +12dB
See 3
CRUSH: OFF - ON
See 3
IN: OFF - ON
See 3
HIGH-MID
FREQUENCY: 450Hz - 13.7kHz
See 3
BANDWIDTH: 0.33 - 3.3 Octaves
See 4
CUT/BOOST: -12dB - +12dB
See 3
CRUSH: OFF - ON
See 3
IN: OFF - ON
See 3
HIGH
FREQUENCY: 1.2kHz - 20kHz
See 3
SLOPE: 6dB / 12dB
Sets by how much or ‘fast’ the signal is attenuated in dB’s per octave at the High frequencies. 6dB per
octave is more gentle and therefore more musical than 12dB, however, at 12dB per octave the signal is
‘focused’ but attenuation more noticeable.
CUT/BOOST: -12dB - +12dB
See 3
CRUSH: OFF - ON
See 3
IN: OFF - ON
See 3
5
6
4
