ENGLISH
5
Network speed and network components
Please ensure that the upload speed of your Internet connection is at least 0.5 Mbps. You can also carry out
a speed test at any time via the DoorBird App. The user experience is only as good as your network speed,
network stability and quality of your network components, such as your Internet Router and WiFi access points
or WiFi repeaters. Please also make sure that your network components are no older than two years, have been
manufactured by a well-known manufacturer, and have the latest firmware installed.
Should these requirements not be fulfilled, it may occur, for example that the performance of audio and video is
poor or push notifications are delayed or do not arrive on your smartphone or tablet at all.
Requirements:
High-speed Internet (via landline): DSL, cable or optical fibre
Network: Ethernet, with DHCP
SWITCHING OFF POWER
Switch off the power to all wires leading to
the assembly location, i.e. the door chime,
electric door opener, power supply unit for
the video door station etc.
DISMANTLING THE EXISTING
DOORBELL
Should there already be a doorbell or door station on
the exterior wall of the house, please dismantle it.
DETERMINING THE ASSEMBLY LOCATION
The device uses an ultra wide-angle hemispheric lens so that even when the person is a minimum distance of
50 cm (19.68 in) away from the device, a low installation height is sucient. The lens is therefore not mechanically
adjustable. The camera lens should be located at an altitude of at least 145 cm (57 in). You may check this prior to
the final mounting.
When choosing the assembly location, consider the lighting conditions. Avoid direct sunlight, direct backlight
and reflective surfaces.
NOTICE
Do not expose the device to direct sunlight.
The housing temperature can exceed the
maximum allowed temperature limit.
This can result in damage of electric and
mechanic components of the device and
injuries especially when touching exterior
parts of the device. White and bright silver-
colored front plates absorb less sunlight than
dark ones.
NOTICE
An image sensor must not be exposed to
direct sunlight for an extended period of
time. Direct sunlight will “blind” the camera
and may permanently bleach the small color
filters on the image sensor chip.
Any defects caused by direct sunlight are not
covered by warranty.
The network cable between the device and the PoE-Switch/PoE-Injector/Internet Router can have a maximum
length of 80 meters/262 feet (IEEE 802.3).
If you have only two wires available at the assembly location, you may use of the “DoorBird 2-Wire
Ethernet PoE Converter A1071”, sold separately. It allows you to transfer network data (Ethernet) and
power (PoE) with a simple two-wire cable over long distances. For example; existing buildings with a
simple two-wire bell wire can be equipped with network technology without having to retrofit any
network cables.
