EN
• Check that all mounting fasteners are securely fastened and that
the paint marks are aligned.
• Inspect the mounting structure for any signs of damage.
• Inspect the gyro for visible signs of damage or fluid leaks.
• Check that the raw water seacock is open.
• Check that the raw water strainer is clear of debris.
WARNING! Risk of structural damage
The gyroscopic stabilizer exerts large forces on the boat's
structure that must be withstood by the mounting system.
Do not operate the gyro if any of the paint marks on the
mounting fasteners are not aligned.
Do not operate the gyro if there is any sign of damage to
the mounting structure.
If the paint marks are not aligned or there is damage to
the mounting structure, take the boat to an authorized
service facility.
8.2 Starting the gyro
WARNING! Pinch point hazard
Moving parts can crush and cut.
Do not operate the gyro without all covers in place.
Do not reach into gaps in the covers.
1. Turn on the house power to the gyro using your boat's battery
switches and/or circuit breakers.
The system power LED indicator on the touch pad comes on.
2. Push the power button on the touch pad or MFD.
The flywheel starts to spin up. The touch pad and MFD show
the status as follows:
Touch pad The power button's white LED comes on. The flywheel
speed progress bar lights up as speed increases.
MFD The power button turns blue. A small up arrow shows
that the flywheel speed is increasing. The flywheel
speed progress bar fills up as speed increases.
3. Push the stabilize button on the touch pad or MFD.
The gyro will start stabilizing when the flywheel reaches the
minimum stabilizing speed. The touch pad and MFD show the
status as follows:
Touch pad The stabilize button's white LED pulses until stabilizing
begins, at which time the LED comes on continuously.
MFD The stabilize button turns blue. The boat icon pulses un-
til stabilizing begins.
NOTE If you do not want stabilization to start
automatically, do not push the stabilize button until you
are ready.
NOTE You may start and stop stabilizing at any time.
There may be some conditions in which you do not want
the stabilizing function to operate.
8.3 Stopping the gyro
Push the power button on the touch pad or MFD.
The gyro enters regeneration mode, which slows the flywheel
down by using the motor as a generator to charge the
dedicated 48 V battery. The touch pad and MFD show the
status as follows:
Touch pad The white LED in the power button pulses to indicate
that the flywheel is slowing down. The flywheel speed
progress bar segments turn off as speed decreases.
MFD The power button turns gray. A small down arrow shows
that flywheel speed is decreasing. The flywheel speed
progress bar empties as speed decreases.
NOTE The dedicated 48 V battery must remain
connected to the gyro. If you switch the battery off, the
gyro will go into a fault state and it will take about eight
hours for the flywheel to stop spinning.
9 Cleaning and maintenance
The Dometic gyroscopic stabilizer is designed to require very
little maintenance. Like all equipment that operates in a marine
environment, periodic inspection and maintenance is required to
maximize the service life of your equipment.
Most of the system maintenance and inspection must be
performed by a qualified marine technician, but there are some
more frequent inspections that you should do as an owner:
Task Interval
Check that the four gyro mounting fasteners are se-
cure and the paint marks are aligned. See Pre-start
system inspection on page7
Before every use
Check that the raw water strainer is not blocked by
debris. To clean the strainer, see section Cleaning
the raw water strainer on page9
Before every use
If the gyro is installed in a wet space, check that salt
residue is not collecting on the gyro. Clean the ex-
posed parts of the gyro with mild soapy water to
remove salts that cause corrosion.
Monthly
Check the coolant level. See Coolant level check
on page9. A change in coolant level indicates
a problem in the cooling system that must be ad-
dressed.
Monthly
8
