EN
Raw water automatic maintenance cycle
The raw water pump will periodically run at an increased flow rate
to flush the raw water system. You may notice more flow out of
the discharge outlet than normal while this maintenance cycle is
active.
9.1 Cleaning the raw water strainer
The raw water strainer is mounted to the inlet of the raw water
pump. The strainer should be cleaned periodically, or whenever
debris is seen inside.
1. Close the seacock.
2. Remove the bowl from the strainer.
On the strainer supplied by Dometic, the bowl unscrews from
the body by hand. Your builder or installer may have used
a different strainer, in which case removal of the bowl may
require tools.
3. Clean the bowl and the filter element.
4. Install the bowl on the strainer by reversing step 2 on
page9.
Make sure that the bowl seal is clean and not damaged.
Take care when installing the bowl that the seal does not get
twisted, damaged, or moved out of place.
5. Open the seacock.
6. Check that there is no leak from the strainer bowl.
9.2 Coolant level check
The gyro must be stopped for at least two hours to ensure the
coolant is at ambient temperature before checking the level.
1. Disconnect power to the gyro using the battery switches.
WARNING! Pinch point hazard
Moving parts can crush and cut.
Keep covers in place.
Keep hands clear while operating.
Confirm flywheel is stationary and disconnect
power before removing covers for maintenance.
2. Remove the top cover from the gyro.
To remove: li up on the front corners of the cover until the
ball and socket joints detach, then rotate the cover up to
detach the joints at the rear of the cover.
3. Check that the fluid level in the coolant tank is between the
MIN and MAX markings on the tank.
NOTE A fluid level outside these limits indicates
that there is a problem in the cooling system. Do not
operate the gyro until the cooling system has been
inspected by a qualified marine technician.
MAX
MIN
4. Re-install the top cover.
To install: set the cover in place, then push down at each
corner until the balls snap into the sockets.
5. Re-connect the power to the gyro.
9
