11
4.2. ELECTRICAL CONNECTION (Fig. 4A-Tab.A).
IMPORTANT! Before connecting, make sure the mains voltage and frequency match that given on
the dataplate.
ATTENTION!
Work on the electrical systems must only be carried out by a qualied electrician.
Before carrying out any cleaning or maintenance operation, disconnect the appliance
from the power supply and carefully unplug it.
IMPORTANT! Before connecting make sure:
- the mains voltage and frequency match that given on the dataplate and that there is an ecient earth
contact.
-
the system power supply is arranged and able to take the actual current absorption and that it is
correctly executed according to the regulations in force in the country of use
;
IMPORTANT! The manufacturer declines any liability if the safety regulations are not respected.
•
After making the connection, with the machine working check that the power supply does not uctuate
by ±10% the rated voltage.
• Installation requires the inclusion of a device lockable in the “open” position during maintenance.
4.2.1. Power cord -
• Provide a standardized accessible 2-pole + ground wall power outlet, 16A rated according to
IEC60309, and a corresponding waterproof plug to be mounted on the power cord.
If the appliance is directly tted to supply main, supply mains shall have contact separation in all poles
that provide full disconnection under overvoltage category III conditions, in accordance with wiring
rules.
Note: For Australia and New Zealand, the wiring shall be in accordance with AS/NZS 3000.
If the power cable is damaged, it must be replaced by the after-sales service or in any
case by qualied personnel, in order prevent any risk.
The manufacturer declines any liability for damage or injury resulting from breach of
the above rules or non-compliance with the electrical safety regulations in force in the
country where the machine is used.
4.2.2. CIRCUIT BREAKER
Install a circuit breaker ahead of the appliance. Contact opening distance and maximum leakage current
must comply with current regulations.
• Appliance max. leakage current is 1 mA/kW.
4.2.3. EARTHING CONNECTION AND EQUIPOTENTIAL BONDING
• It is essential to connect the device to an earthed outlet.
Connect the device to an earthed outlet; then include it in an equipotential bonding using the screw
located at the back right of the device. The screw bears the symbol.
4.3. CONNECTING TO THE WATER SUPPLY
The appliance must be supplied with potable water at a pressure ranging from between minimum 0,15
and maximum 1 MPa (1.5 - 10 bars).
Caution! If the water pressure exceeds 0.3 MPa (3 bars), use a pressure reducer to prevent damage
to the appliance. To perform the installation correctly, it is essential to connect the water inlet pipe to
