- 41 -
it is used to program when to use grid or
generator to charge the battery, and when to discharge
the battery to power the load. Only tick "Time Of Use"
then the follow items (Grid, charge, time, power etc.)
will take effect.
Time Of Use
Time
System Work Mode
Batt
Grid
Charge
Gen
00:00
05:00
09:00
10:00
15:00
18:00
05:00
08:00
10:00
15:00
18:00
00:00
Power
32000
32000
32000
32000
32000
32000
160V
160V
160V
160V
160V
160V
Work
Mode2
if battery SOC is lower than 80%, it will use grid to charge the
battery until battery SOC reaches 80%.
if battery SOC is higher than 40%, hybrid inverter will discharge
the battery until the SOC reaches 40%. At the same time,
if battery SOC is lower than 40%, then grid will charge the
battery SOC to 40%.
if battery SOC is higher than 40%, hybrid inverter will discharge
the battery until the SOC reaches 40%.
If battery SOC is lower than 80%, hybrid inverter will charge the
battery until the SOC reaches 80%. If the PV power is sufficient, the
battery can be charged to 100%.
when battery SOC is higher than 40%, hybrid inverter will discharge
the battery until the SOC reaches 40%.
when battery SOC is higher than 35%, hybrid inverter will discharge
the battery until the SOC reaches 35%.
Time Of Use
Time
System Work Mode
Batt
Charge
Gen
00:00
05:00
08:00
10:00
15:00
18:00
05:00
08:00
10:00
15:00
18:00
00:00
Power
80%
40%
40%
80%
40%
35%
Work
Mode2
32000
32000
32000
32000
32000
32000
Grid
②
Grid Charge
Gen Charge
Grid SignalGen Signal
Gen Max Run Time 0.0 hours
Gen Down Time 0.5 hours
Battery Setting
Start
A
30% 30%
80A
80A
Batt
Set2
It allows users to choose which day to execute the
setting of "Time of Use".
For example, the inverter will execute the time of use
page on Mon/Tue/Wed/Thu/Fri/Sat only.
Mon
System Work Mode
Tue Wed Thu Fri Sat Sun
Work
Mode4
when in selling first mode and click time of use, the battery
power can be sold into grid.
uses the grid to charge the battery in the selected
period of time.
utilize diesel generator to charge the battery
in the
selected period of time.
real time, from 0:00 to 0:00 the next day.
For more flexible and controllable use of batteries, it is
recommended to enable the "Time Of Use" function.When the
inverter is operating in on-grid mode and "Time Of Use" is not
enabled, the inverter can charge normally, but only discharge to
provide the inverter's self-consumption power, without discharging to
power the loads.
Max. discharge power of battery allowed.
The target value of battery voltage or SOC during
the current time period. If the actual SOC or voltage of the battery is
lower than the target value, the battery needs to be charged. If there
is a energy source like solar power or grid, the battery will be
charged; If the actual SOC or voltage of the battery is higher than the
target value, the battery can discharge, and when the solar power is
not enough to power the load or the "Selling First "is enabled, the
battery will discharge.
Assuming that at the end of the previous time period, the actual
battery level reaches or approaches the target value of the previous
time period.
