- 40 -

Zero Export To Load
Max Solar Power
Zero Export To CT
Max Sell Power
Energy pattern
BattFirst LoadFirst
System Work Mode
Solar Sell
Solar Sell
32000
32000
Power
28000
Zero-export Power
20
Selling First
Work
Mode1
Grid Peak Shaving

󾗺 This Mode allows hybrid inverter to sell
back any excess power produced by the solar panels to
the grid. If time of use is active, the battery energy also
can be sold into grid.
The PV energy will be used to power the load and charge
the battery, then the excess will flow to grid.
Power source priority for the load is as follows:
1. Solar Panels.
2. Batteries(when the actual battery SOC is higher than
the target SOC).
3. Grid.
󾗺 the maximum DC input power allowed.
Grid
Backup Load
On-Grid Home Load
Battery
Solar
Grid
Backup Load
On-Grid Home Load
Battery
Solar
CT
󾗺 Hybrid inverter will only provide power to the backup load connected. The hybrid inverter
will neither provide power to the home load nor sell power to grid,if the "solar sell" behind is not enabled. The
built-in CT will detect power flowing back to the grid and will reduce the power of the inverter only to supply the
backup load and charge the battery. 
󾗺 Hybrid inverter will not only provide power to the backup load connected but also give power
to the home load connected. If PV power and battery power is insufficient, it will take grid energy as supplement.
The hybrid inverter will not sell power to grid,if the "solar sell" behind is not enabled. In this mode, external CTs or
smart meter must be installed. For the installation method of CTS or smart meter, please refer to the section 3.7 .
The external CTs or smart meter will detect power flowing back to the grid and will reduce the power of the inverter
only to supply the backup load, home load and charge the battery. 
"Solar sell" is selectable for Zero export to load or Zero export to CT. When activating it, the surplus of
the energy generated by the PV can be sold back to grid. When it is active, the energy generated by the PV array
will first power the loads or charge the battery, and then export to grid.
 Maximum power allowed to flow to grid.
 This parameter will ensure the zero-export by taking from the grid some small amount of
energy that has been set with this value. It is recommended to set it as 20-100W to ensure the hybrid inverter won'
t feed power to grid.
󾗺 Priority of PV power usage. When "Grid charge" is enabled, the default energy pattern is "Load
First", this setting will be invalid.
󾗺 PV power is firstly used to charge the battery, and the excess power will be used to power the load. If
PV power is insufficient, grid will make supplement for battery and load simultaneously.
󾗺 PV power is firstly used to power the load, and the excess power will be used to charge the battery. If
PV power is insufficient, Grid will provide power to load.
 when it is active, grid power will be limited within the set value. If the grid peak-shaving
power plus PV power plus battery power cannot meet the power consumption of the load after peak-shaving, the
grid peak-shaving will be invalid, and the power taken from the grid can exceed this set value.
