69
General procedure
Part MIDI TX channel (default)
Main 1
Coupled 2
Lower 3
Bass 4
Memory 15
Organ control 14
2. If you selected the 'Memory' part, the following page is showed:
Memory
Parameter Setting Explanation
Status
OFF, ON
Default: On
Select 'On' if you want to transmit MIDI
messages when you recall a memory.
See "Working with the Memories" (p.
45).
Channel
1 ~ 16
default: 15
Allows you to assign a MIDI transmit
channel to the 'Memory' part.
3. If you selected the "Organ Control" part, the following page is showed:
Organ Control TX
Parameter Setting Explanation
Status
OFF, ON
Default: On
Select “On” if you want transmit position
MIDI messages of the draw-faders. For details
regarding the MIDI messages transmitted,
see "Draw-faders MIDI Controls" (p. 76).
Channel
1 ~ 16
default: 14
Allows you to assign a MIDI transmit channel
to the "Organ control" part.
4. If you selected the 'Common' part, the following page is showed:
Common
Parameter Setting Explanation
Active Sensing
(FEH)
OFF, ON
Default: On
This MIDI messages is transmitted
constantly at intervals of approximately
250 ms.
This MIDI message is used to monitor
the MIDI connection. If there was a
disconnection, after a connection has
been made, the connected device no
longer receives the active sensing (FEH)
message and reset all notes that have
remained actives messages.
Select 'On' if you want to transmit the
Active Sensing MIDI.
MIDI SET
MIDI Sets are used to store MIDI settings. The VIVO S2 provides ve
MIDI Set memories.
The rst MIDI Set, called 'Dexibell,' is read-only and allows you to
restore the factory MIDI settings.
The second MIDI Set, called 'Keyboard Zone,' is also read-only and
provides a quick way to congure MIDI channels using keyboard
zones. For more details, see "USB MIDI Keyboard Controller" (p.
54).
The remaining three memories (User 1, User 2, User 3) are user-
congurable and allow you to save and recall your custom MIDI
settings.
1. Use the [][] to select the MIDI Set and press the 'RECALL' Function
button to load it.
2. Press the 'SAVE' Function button to jump in the SAVE MIDI SET page.
SAVE MIDI SET
1. Use the [][] to select the MIDI Set memory and press the 'WRITE'
Function button to save your conguration.
EXPORT MIDI SET
You can save your MIDI SET in a USB Memory.
1. Connect the USB Memory to which you wish to save the data. See
"Connecting an USB Memory Device (commercially
available)" (p. 16).
2. Use the 'OPEN' function button to select the folder where you want save
the data.
3. Press the 'EXPORT' function button to perform the export operation.
IMPORT MIDI SET
You can load your MIDI SET previous saved in a USB Memory.
1. Connect a USB Memory containing the previously saved MIDI SET data.
See "Connecting an USB Memory Device (commercially
available)" (p. 16).
2. Use the 'OPEN' function button to select the folder that contains the data.
