68
MENU Options (Advanced Section)
In the example above we selected the Main keyboard part.
Main, Coupled, Lower, Bass
Parameter Setting Explanation
Status
OFF, ON
Default: On
Select 'On' if you want the selected part
to receive MIDI data.
Channel 1 ~ 16
Allows you to assign a MIDI receive
channel to the selected part.
Shift
-48~0~+48
Default : 0
This parameter allows you to transpose
the received note messages before
sending them to the VIVO S2’s tone
generator. The maximum possible
transposition is four octaves up (48)
and down (–48). Each step represents a
semi-tone.
Modulation
OFF, ON
Default: On
These lters allow you to specify
whether (On) or note (O) the messages
in question should be received.
Volume
Panpot
Expression
Aftertouch
Reverb
Hold
Sostenuto
Soft
PG (Program
Change)
PB (Pitch Bender)
Part MIDI RX channel (default)
Main 1
Coupled 2
Lower 3
Bass 4
Memory 15
Organ control 14
2. If you selected the 'Memory' part, the following page is showed:
MEMORY RX
Parameter Setting Explanation
Status
OFF, ON
Default: On
Select 'On' if you want to receive MIDI
messages for the memories selection.
Channel
1 ~ 16
default: 15
Allows you to assign a MIDI receive
channel to the 'Memory' part.
3. If you selected the 'Organ Control' part, the following page is showed:
Organ Control RX
Parameter Setting Explanation
Status
OFF, ON
Default: On
Select 'On' if you want to receive virtual
draw-faders MIDI messages. For details
regarding the MIDI messages received,
see "Draw-faders MIDI Controls" (p. 76).
Channel
1 ~ 16
default: 14
Allows you to assign a MIDI receive
channel to the 'Organ control' part.
TRANSMISSION
You can congure the MIDI transmission parameters of Main,
Coupled, Lower and Bass part. Additionally, you can manage the
transmitted MIDI messages for the memories control. Selecting
the 'Common' you can decide whether to send or not the 'Active
Sensing' MIDI messages.
1. Select the part you want to edit (Main Coupled , Lower and Bass).
In the example above we selected the Main part.
Main, Coupled, Lower, Pedal
Parameter Setting Explanation
Status
OFF, ON
Default: On
Select 'On' if you want the selected part
to transmit MIDI data.
Channel
1 ~ 16
Default: 1
Allows you to assign a MIDI transmit
channel to the selected part.
Shift
-48~0~+48
Default : 0
This parameter allows you to transpose
the note messages before they are
transmitted to an external MIDI device.
The maximum possible transposition is
four octaves up (48) or down (–48).
Local
OFF, ON
Default: On
You can disconnect the part from
the internal sound source ('O') – or
re-establish that connection ('On').
Modulation
OFF, ON
Default: On
These lters allow you to specify
whether (On) or note (O) the messages
in question should be transmitted.
Volume
Panpot
Expression
Aftertouch
Reverb
Hold
Sostenuto
Soft
PG (Program
Change)
PB (Pitch Bender)
