EnGLIsh
2. Lift the rear door cover
20
and hook rear side discharge
chute
24
onto themower and engage slot on left as shown
in Fig. O.
3. Release the rear door cover
20
and ensure the rear side
discharge chute
24
is secured in place before operating
themower.
Adjusting Mower Height (Fig.P)
The height of cut is adjusted by the cut height adjustment
lever
19
.
nOTE: If you are not sure which height to mow at, begin mowing
with the cut height adjustment leve
r
19
positioned at the highest
setting and adjust height down as needed for yourapplication.
To Set the Height of Cut
1. Pull the cut height adjustment lever
19
out of the locking
notch
38
.
2. Move the cut height adjustment lever
19
towards the rear
of the mower to raise the height ofcut.
3. Move the cut height adjustment lever
19
towards the front
of the mower to lower the height ofcut.
4. Push the cut height adjustment lever
19
into one of the
lockingnotches
38
.
Headlights (Fig. A)
Headlights
25
are always on when mower is powered on.
Battery Switch (Fig. Q)
Mower can toggle between two batteries by using the battery
switch
26
located behind the motor. Switch will point to the
battery pack powering the mower.
nOTE: Mower can operate with only one battery installed.
WARNING: Turn unit off prior to toggling the battery
switch.
OPERATION
DANGER: To reduce the risk of serious personal
injury, turn unit off and remove the safety key and
battery pack(s) before making any adjustments or
removing/installing attachments or accessories. An
accidental start-up can causeinjury.
Proper Hand Position (Fig.R)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires both hands grasping the main
handle
4
and bail handle
8
together when not in self-propel
mode; and both hands grasping the main handle, bail handle,
and self drive lever
9
together when in self-propel mode as
shown in Fig. R.
READ THIS INSTRUCTION MANUAL
BEFOREOPERATING YOUR MOWER
Refer to Fig. A at the beginning of this manual for a list
ofcomponents. Save this manual for futurereference.
DANGER: Sharp moving blade. Do not operate the
mower in mulching mode if the rear door is not closed
under spring tension as serious injury could result. Take
your mower to the nearest service center forrepair.
DANGER: Do not operate mower unless handle is locked
intoposition.
DANGER: Sharp moving blade. Never operate the
mower in bagging mode unless the bag lugs on the grass
collection bag are seated properly on the mower and the
rear door rests firmly against the top of the grass collection
bag as serious injury couldresult.
DANGER: Sharp moving blade. Do not operate the
mower in side discharge mode unless the rear side
discharge chute is properly installed with the rear door
cover resting firmly againstit.
WARNING: Let the mower work at its own pace. Do
notoverload.
Installing and Removing the Battery Pack(s)
(Fig.S)
DANGER: MAKE CERTAIN THE SAFETY KEY IS
REMOVED TO PREVENT ACTUATION BEFORE
REMOVING OR INSTALLINGBATTERY.
nOTE: Always make sure the battery port cover
18
is fully
closed after inserting or removing the batteries and remains
closed during operation and storage.
The mower will turn off and the overheat indicator
13
will blink
if the battery pack(s) reaches the high temperature limit, which
can be caused by cutting heavy grass. If this occurs, allow the
battery pack(s) to cool and then resume cutting with the mower
deck sethigher.
nOTE: For best results, make sure the battery pack(s) is
fullycharged.
To Install Battery Pack(s)
1. Lift and hold the battery port cover
18
up to expose the
battery port
39
.
2. Slide a battery pack(s)
27
into the battery port
39
until an
audible click is heard (Fig. S).
nOTE: Ensure the battery pack(s) is fully seated and fully
latched intoposition.
3. Close the battery port cover
18
. Ensure the battery port
cover is fully closed before startingmower.
To Remove Battery Pack(s)
1. Lift and hold the battery port cover
18
up to expose the
batteryport
39
.
2. Depress the battery release button
28
and pull the battery
pack(s)
27
out ofbatteryport.
Fuel Gauge Battery Pack(s) (Fig.C)
Some DEWALT battery pack(s) include a fuel gauge, which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
