ENGLISH
removing/installing attachments or accessories. An
accidental start-up can causeinjury.
Single Touch Handle Adjustments (Fig.D, E)
The mower is shipped in the storage position. You will need
to adjust the single touch handle
1
to the operating position
beforecontinuing.
Raise the Single Touch Handle (Fig.D, E)
1. To unlock the single touch handle
1
from the storage
position, squeeze the handle unlock button
3
.
NOTE: The handle unlock button
3
is located on the back
of handle support
2
.
NOTE: The main handle
4
must pop out slightly from both
sides of the single touch handle tubes before lifting the
single touch handle
1
from the storageposition as shown
in Fig. D.
2. Raise the single touch handle
1
to the locked position.
Listen for an audible click and ensure the single touch
handle
1
is locked intoposition beforeproceeding.
3. Extend the main handle
4
outward until a set of audible
clicks is heard. The single touch handle
1
is now in the
operationposition.
NOTE: Take care to not pinch, pull or otherwise stress
thecord
29
.
Adjusting the Main Handle Height (Fig.F)
The main handle
4
extends to accommodate tallerusers.
1. To extend the main handle
4
to the lower height position,
press the handle release button
5
and pull the main
handle away from the handle support
2
until an audible
click is heard, indicating that it is locked into the lower
heightposition.
NOTE: The handle release button
5
is located on the
bottom of handle support
2
.
2. To extend the main handle
4
to the upper height position,
press the handle release button
5
and pull the main
handle away from the handle support
2
until an audible
click is heard, indicating that it is locked into the upper
heightposition.
3. Ensure the main handle
4
locks intoposition
beforeproceeding.
NOTE: When the battery pack(s)
27
and safety key
6
are
inserted and the bail handle
8
is pulled, the handle folding
indicator
15
will illuminate if the single touch handle
1
is
not locked intoposition.
4. To retract the main handle
4
to the lower height position,
press the handle release button
5
and push the main
handle
4
towards the handle support
2
until an audible
click is heard, indicating that it is locked into the lower
heightposition.
5. Ensure the main handle
4
locks intoposition
beforeproceeding.
Storage Mode (Fig.G‑L)
DANGER: MAKE CERTAIN THE SAFETY KEY IS
REMOVED TO PREVENT ACTUATION BEFORE
REMOVING OR INSTALLINGBATTERY.
DANGER: Turn unit off and remove safety key and
batterypack.
1. To retract the main handle
4
, press the handle release
button
5
and push the main handle
4
towards the handle
support
2
until two audible clicks are heard, indicating that
both sides of the handles are locked intoposition. The main
handle
4
must be fully seated against the handlesupport.
NOTE: The main handle
4
must fully engage the handle
windows
30
. If they are not engaged as shown in Fig. G,
press the main handle
4
towards the handle support
2
until two audible clicks areheard and both sides of handle
windows
30
are closed as shown in Fig.H.
NOTE: Ensure the two storage latches
31
at the back of
the single touch handle
1
tubes pop outward as shown in
Fig. J before lowering the single touch handle
1
into the
storageposition.
2. Fold the single touch handle
1
towards the front
wheels
33
into storage
position
. Listen for two audible
clicks as the two storage latches
31
slide into the
storageslots
32
as shown in Fig. K.
3. Ensure the single touch handle
1
is locked intostorage
position beforeproceeding.
4. The mower can be stored standing up, with the collection bag
removed, or flat on itswheels as shown in Fig. L.
NOTE: Take care to not pinch, pull or otherwise stress
thecord
29
.
Grass Collection Bag (Fig.M)
DANGER: Turn unit off and remove safety key and
batterypack.
1. Lift the rear door cover
20
, remove mulching plug
23
,
and place the grass collection bag
21
onto the mower
so the bag lugs
34
slide into the slots
35
on the inside
plastic surfaces of the handle brackets. Then lower the rear
doorcover
20
.
NOTE: If installed, remove rear side discharge chute
24
and
ensure the rear door cover
20
is fullyup before installing
grass collection bag
21
.
Mulching (Fig.N)
DANGER: Turn unit off and remove safety key and
batterypack.
1. To operate mower in mulching mode, remove the grass
collection bag
21
or rear side discharge chute
24
.
2. Lift the rear door cover
20
and slide the mulching plug
23
fully into themower.
3. Ensure the pins
36
on the mulching plug
23
engage the
slots
37
on the mower as shown in Fig. N.
4. Be sure rear door cover
20
isclosed.
Side Discharge (Fig.O)
DANGER: Turn unit off and remove safety key and
batterypack.
1. To operate mower in side discharge mode, remove the grass
collection bag
21
.
NOTE: If installed, remove the mulching plug
23
.
