Je bekijkt pagina 44 van 192
42
ENGLISH
Adjusting the Telescoping Pole Length (Fig. A, P, Q)
(DCMPS635, DCMPS640 Only)
WARNING: Always check to make sure that the threaded
sleeve is completely locked and that the telescoping pole
does not move before using or transporting the pole saw. Not
locking the threaded sleeve could result in the telescoping
pole unexpectedly moving, creating a hazardous condition.
WARNING: Periodically check the threaded sleeve to
ensure that it is completelylocked.
The telescoping pole
3
can be used retracted, extended, or at
any position in between.
1. Unlock the threaded sleeve
13
by twisting it clockwise, as
shown in Fig.P.
2. With one hand firmly grasping the telescoping
assembly
49
, slide the telescoping pole
3
out with the
other hand as shown in Fig.Q. This will reveal the stored
telescopingpole
3
.
3. Once you have reached the desired telescoping length, lock
the threaded sleeve
13
to secure the telescoping pole in place
by twisting it counterclockwise.
4. Ensure the telescoping pole
3
is secured into position
beforeuse.
Saw Chain and Guide Bar Oiling (Fig. J)
Auto Oiling System
The polesaw is equipped with an auto oiling system that keeps
the saw chain and guide bar constantly lubricated.
Attaching and Adjusting the Shoulder Strap (Fig. N, O)
WARNING: The shoulder strap should only be slung over one
shoulder and not across the body. See Fig. O.
A shoulder strap
26
is recommended for any tool with a total
weight exceeding 13lbs. (6 kg). (Total weight includes the tool,
and battery.) Attach the strap
26
to the strap mount
25
as
shown in Fig. N and adjust for proper balance andsupport
1. Attach the strap mount
25
to the insulated hand grip
12
by pinching the tabs on each side of the strap mount as
shown in Fig.
N
.
The strap mount
25
can be positioned
anywhere along the
insulated hand grip
12
to accomodate
different sized users.
2. Snap the shoulder strap latch
45
onto the strap
mount
25
located on the
insulated hand grip
12
, as shown
in Fig.
N
. Adjust the strap so it fits over yourshoulder and
provides proper balance andsupport.
Replacement chains and bars are available from your
nearest authorized servicecentre.
The DCMPS640 pole saw is compatible with the following
DeWALT accessories when using the supplied .325 pitch,
7-tooth sprocket
42
(NA265339):
SAW CHAINS GUIDE BARS
25cm (10") DZO6525-QZ 25cm (10") DZO6425-QZ
30 cm (12") DZO6530-QZ 30 cm (12")
DZO6430-QZ
The DCMPS635 pole saw is also compatible with the following
DeWALT accessories when using the 3/8" pitch, 6-tooth
sprocket(90585879):
SAW CHAINS GUIDE BARS
25 cm (10") DZO6325-QZ 25 cm (10")
DZO6225-QZ
2. Remove sprocket cover
17
as described in Installing the
Guide Bar and Saw Chainsection.
3. Rotate the chain tension screw
19
using the flat screwdriver
end of thewrench
24
. Turning the screw counterclockwise
allows the guide bar
15
to recede and reduces the tension on
the chain so that it may beremoved.
4. Wearing protective gloves, grasp the saw chain and lift the
worn saw chain out of the groove in the guidebar.
5. Flip guide bar over every time you replace the chain to
ensure evenwear.
6. Place the new chain in the slot of the guide bar, making sure
the saw teeth are facing the correct direction by matching the
arrow and graphic of the saw chain on the sprocket cover
17
as
shown in Fig.K, M.
7. Follow instructions for Installing the Guide Bar and SawChain.
1. The oil level indicator
21
shows the level of the oil in the oil
reservoir. If the oil level is less than a quarter full, remove the
battery and refill the oil reservoir with the correct type of oil.
2. Always empty oil reservoir when finishedcutting.
3. Always empty oil reservoir before storing this unit.
NOTE: Do not operate the polesaw without oil.
NOTE: Always use a high-quality, biodegradable bar and chain
oil for proper saw chain and bar lubrication. When pruning
trees, vegetable-based bar and chain oil is recommended, as
mineral-based oils may harm living trees. Never use dirty, used,
or contaminated oil. Doing so may damage the tool.
Filling the Oil Reservoir
1. Unscrew counterclockwise and then remove the oil cap
22
.
Fill the reservoir with the recommended bar and chain oil until
the oil level has reached the top of the oil level indicator
21
.
2. Refit the oil cap and tightenclockwise.
NOTE: Do not overtighten. There are alignment marks on the
oil cap and tank. The cap only needs to be tightened until those
marks align.
3. Periodically switch the saw off and check the oil level
indicator
21
to ensure the bar and chain are being
properlyoiled.
Adjusting the Guide Bar Oil Flow (Fig. J)
This DCMPS635 and DCMPS640 are equipped with an adjustable
oiling system. The flow of saw chain and guide bar lubrication can
be set for different types of wood and cutting techniques. The
saw chain and guide bar lubrication feed rate is suitable for most
applications when the oil flow adjust screw
46
is in positioned in
between the maximum
47
and minimum
48
positions.
To reduce the flow:
1. Using the screwdriver end of the wrench
24
, twist
the oil flow adjust screw
46
clockwise towards the
minimum
48
positions.
To increase the flow:
1. Using the screwdriver end of the wrench
24
, twist the oil flow
adjust screw
46
counterclockwise maximum
47
position.
