7. Follow the procedure in After working inside your computer.
Camera module
Removing the camera module
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SIM card (optional).
3. Remove the base cover.
4. Remove the 5G WWAN card.
5. Remove the display assembly.
6. Remove the display bazel.
7. Remove the display panel.
About this task
The following images indicate the location of the camera module and provide a visual representation of the removal procedure.
Figure 55. Removing the camera module
Removing and installing Field Replaceable Units (FRUs)
109
