11
About your monitor
Monitor specifications
Table 5. Monitor specifications.
Description Value
Screen type Active matrix - TFT LCD
Panel Type In-Plane Switching (IPS) Technology
Aspect ratio 16:9
Viewable image dimensions
Diagonal 684.70 mm (27.00 in.)
Active Area
Horizontal 596.74 mm (23.49 in.)
Vertical 335.66 mm (13.21 in.)
Area 200301.75 mm
2
(310.47 in.
2
)
Pixel pitch 0.1554 mm x 0.1554 mm
Pixel per inch (PPI) 163
Viewing angle
Horizontal 178° (typical)
Vertical 178° (typical)
Brightness
White Luminance 400 cd/m
2
(typical)
600 cd/m
2
(HDR peak)
Contrast ratio 1000:1 (typical)
Display screen coating Anti-glare with hard-coating 3H
Backlight LED Edgelight System
Response Time
(Gray to Gray)
0.5 millisecond (gray-to-gray min), 1 millisecond (gray-to-gray most observed) in
Extreme Mode
2 milliseconds gray to gray in Super Fast Mode
3 milliseconds gray to gray in Fast Mode
Color depth 1.07 Billion colors (8 bit + A-FRC)
Color gamut DCI-P3 Typical 95% (CIE 1976)
sRGB Typical 100% (CIE 1931)
Calibration accuracy sRGB
Delta E≤2 (Average)
Connectivity • Two HDMI 2.1 ports (HDCP 1.4 and HDCP 2.2), (Supports 4K 3840 x 2160 at
165 Hz, FHD 1920 x 1080 at 330 Hz, FRL, HDR, VRR as per specied in HDMI
2.1)
NOTE: Refresh rate can be overclocked up to 180 Hz in 4K mode and up to
360 Hz in FHD mode.
NOTE: Additionally, one of the two HDMI 2.1 ports with FRL supports eARC/
ARC for Dolby ATMOS pass-through.
• One DisplayPort 1.4 connector (HDCP 1.4 and HDCP 2.2), (Supports 4K 3840 x
2160 at 165 Hz, FHD 1920 x 1080 at 330 Hz, DSC, HDR)
NOTE: Refresh rate can be overclocked up to 180 Hz in 4K mode and up to
360 Hz in FHD mode.
• One USB-B 3.2 Gen1 upstream port (5 Gbps)
• Two USB-A 3.2 Gen1 downstream ports (5 Gbps)
Quick Access
• One USB-C 3.2 Gen1 downstream port (5 Gbps)
• One USB-A 3.2 Gen1 downstream port (5 Gbps) with BC1.2 power charging
Border width (edge of monitor to active area)
Top
Left/Right
Bottom
7.35 mm
7.35 mm
18.17 mm
Adjustability
Height adjustable stand Up to 110 mm
