10
About your monitor
Bottom view
2 3 41 5 6
7 8 9 1110 12
Figure 3. Bottom view of the monitor
Table 4. Bottom view of the descriptions.
Label Description Use
1
Power connector
Connect the power cable (shipped with your monitor).
2
USB Type-B upstream port
(data only)
Connect the USB cable (shipped with your monitor) to this port and your computer
to enable the USB ports on your monitor.
3,4,7
Super speed USB 5 Gbps (USB 3.2
Gen1) Type-A downstream ports
(3) (data only)
Connect your USB peripherals such as mouse and keyboard.
NOTE: To use these ports, you must connect the USB upstream cable (shipped
with your monitor) between the monitor and the computer.
NOTE: Port 7 supports Battery Charging Rev. 1.2.
5 Barcode, serial number, and
Service Tag label
See this label if you must contact Dell for technical support. The Service Tag is a
unique alphanumeric identifier that enables Dell service technicians to identify the
hardware components in your computer and access warranty information.
6 Joystick Use it to control the OSD menu and Dual-Resolution switching.
8
SuperSpeed USB 5 Gbps (USB 3.2
Gen1) Type-C downstream port
with Power Charging (data only)
Connect to charge your USB device.
NOTE:
To use this port, you must connect the USB cable (shipped with your
monitor) to the USB upstream port on the monitor and to your computer.
NOTE:
To prevent signal interference, avoid connecting other USB devices to
the adjacent port when using a wireless USB device on a downstream USB port.
9 Security lock slot
(based on Kensington Security
Slot)
Secures monitor with security cable lock (sold separately).
10
HDMI 1 port
Connect your computer with the HDMI 2.1 cable (shipped with your monitor) to
this port.
NOTE: To stream Dolby ATMOS audio, connect another HDMI 2.1 cable (sold
separately) to the HDMI 2 eARC/ARC port simultaneously.
11
HDMI 2 eARC/ARC port
Connect your computer or an external audio system with the HDMI 2.1 cable
(shipped with your monitor) to this port.
NOTE:
This port supports eARC/ARC audio output with HDMI CEC turned on.
12
DisplayPort
Connect your computer with the DisplayPort cable (shipped with your monitor) to
this port.
